Silicon Resin Covered Insulation FG Sleeving 2.5KV

FOB Price

Negotiable / Meter

5000 Meters(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

DSG has very good softness and elasticity, excellent high
temperature resistance and good dielectric strength.

Description: DSG is fiberglass braided sleeving coated with silicone resin/rubber and processed by high temperature.

Standard voltages: DSG-1(1.5KV),DSG-2(2.5KV),DSG-3 (4KV), DSG-4 (7KV), DSG-5(10kV).

Thermal class: H

Certificate: UL File E257342- UL1441 VW-1 RoHS-confirm according to 2002/95/EC

Application: DSG is widely used in wiring insulation and mechanical protection for electric motors, transformers and electrical instruments.

Color: Selected

Voltage Breakdown	DSG-1: 1500 Volt; DSG-2: 2500 Volt; DSG-3: 4000 Volt; DSG-4: 7000 Volt; DSG-5:10000 Volt.
Flexibility under low Temperature	No cracking and resin off under -10°C by 24h
Inside Dia. (mm)	Tolerance(mm)	Wall thickness(mm)
Inside Dia. (mm)	Tolerance(mm)	DSG-1	DSG-2	DSG-3	DSG-4	DSG-5
0.5—2.5	+0.3	0.40±0.12	0.41±0.12	0.43±0.12	0.47±0.12	0.51±0.12
3.0—4.5		0.46±0.13	0.48±0.13	0.51±0.13	0.54±0.13	0.59±0.13
5.0—8.0		0.50±0.15	0.52±0.15	0.55±0.15	0.59±0.15	0.64±0.15
9.0—12.0		0.60±0.18	0.62±0.18	0.66±0.18	0.70±0.18	0.75±0.18
14.0-16.0		0.62±0.18	0.65±0.18	0.80±0.18	0.85±0.18	0.96±0.18
18.0-25.0		0.64±0.18	0.66±0.18	0.82±0.18	0.86±0.18	/
26.0-32.0		0.66±0.18	0.68±0.18	0.88±0.18	0.92±0.18	/
