Home > Products > vehicle mounted lift platform > Vehicular Aerial Work Platform Vehicle Mounted Boom Lift Platform
Vehicular Aerial Work Platform Vehicle Mounted Boom Lift Platform
US$ 15,000 - 30,000
/ Set
1 Set(Min. Order)
- qingdao
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | jinchuan | |
| Model Number | GKT-14 | Lift Mechanism | Articulated Lift | |
| Lift Drive / Actuation | Hydraulic | Power | 15horsepower | |
| Rated Loading Capacity | 160kg | Min. Lifting Height | 2950MM | |
| Max. Lifting Height | 12.5M | Table Size | 600*600 | |
| Overall Dimensions | 5100*1950*2950 | Weight | 2000KG | |
| Certification | ISO 9001 | Warranty | ONE YEAR | |
| After-sales Service Provided | No overseas service provided |
Product Description
Specifications
Specifications1aerial work platformfolding-arm lift table for the use of indoor and outdoor high-altitude operations.
2,CE
Vehicular aerial work platform
Introduction:
folding-arm lift table for the use of indoor and outdoor high-altitude operations. With their own take, since the outrigger, simple operation, easy to use, large operations, in particular to cross certain obstacles or in a take-off and landing can be more characteristic of high-altitude operations. Widely used in roads, terminals, shopping malls, stadiums, residential property, factories and mines operating large-scale workshop
Models list:
type | working height(m) | horizontal reach(m) | rotation angle(.) | load(kg) | lifting speed(M/S) | Dimensions (L*W*H)mm | operating pressure (Mpa) | weight kg | travel speed (km/h) | wind loading rating |
GTZ-6 | 7.7 | 1.5 | 360· | 160 | 0.04-0.07 | 2300*880*2020 | 8 | 500 | 15-20 | ≤5 |
GTZ-8 | 9.7 | 2.2 | 360· | 200 | 0.04-0.07 | 2800*1200*2450 | 8 | 700 | 15-20 | ≤5 |
GTZ-10.5 | 10.5 | 3.4 | 360· | 160 | 0.05-0.09 | 3500*1700*2900 | 10 | 1600 | 15-30 | ≤5 |
GTZ-12 | 12 | 3.4 | 360· | 160 | 0.05-0.09 | 3800*1900*2900 | 10 | 1900 | 15-30 | ≤5 |
GTZ-13 | 13 | 4 | 360· | 160 | 0.05-0.09 | 3900*1950*3000 | 10 | 2000 | 15-30 | ≤5 |
Pictures show:
Contact Us
- Jinan Jinchuan Hydraulic Machinery Co., Ltd.
- Contact nameAbery liu Chat Now
- Phone86-0531-84231376
- Address(2nd Workshop, From East To West, West Plant Of T Shaped Crossing, Yuqian Village) South Side, Middle Section Of Taixing Rd., Jibei Development Zone, Jiyang County
