Lithium Battery A Size ER18505 3.6v 3500mah Lithium Battery

Shenzhen Chipu Electronic Technology Ltd.
Lithium Battery A Size ER18505 3.6v 3500mah Lithium Battery thumbnail-1
Lithium Battery A Size ER18505 3.6v 3500mah Lithium Battery photo-1
Negotiable MOQ: 200 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ctech
Model Number:
ER18505
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen/hk
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name ctech
Model Number ER18505
Battery Type LiSOCl2
Nominal Voltage Other, 3.6V
Size Other, 18.5*50.5
Nominal Capacity 3500mAh

Specifications

er18505
Stable performance
strong adoption to the invironment
best choice for indurstruial useage

er18505



ER18505 LiSOCl2
Stable performance
strong adoption to the invironment
best choice for indurstruial useage
0 self discharge



Nominal Capacity:3500mAh

Nominal Voltage: 3.7V

Dimension: Diameter14mm length50.5mm

Continuous Discharge current:100mA

Max Discharge Current:200mA



ER18505 battery  Details:



Features:



1. High energy density

2. High open circuit voltage

3. Stable operating voltage and current

4. Wide operating temperature range, -55°C~+85°C.

5. Long shelf life, more than 10 years for low power equipment

6. Low self-discharge rate (less than 1% at room temperature per year)

7. Stainless steel can and cover

8. Hermetic glass-to-metal full sealed, laser welding, no leak

9. Non-flammable electrolyte

10 .Superior drain capacity



Technical Specifications:



Battery IEC Code

ER18505

Battery Size Code

A

Electrical Characteristics



Nominal Voltage

3.6V

Nominal Capacity

3800mAh

Open circuit voltage

3.66V (at +20°C)

Cut off Voltage

2V

Max. Constant Current

100mA

Max. Pulse Current

200mA

Operating Temperature

-55°C~+85°C/-67°F~+185°F

Storage Temperature

+30°C/+86°F max

Storage Life

≥10 years

Self – Discharge Rate:

<1% per year

Physical Characteristics



External Diameter (Max)

18.5mm/0.73inch

External Height (Max)

50.5mm/1.99inch

Weights

32g/1.13oz

Battery Technology

Lithium thionyl chloride / LiSOCL2

Battery type

High capacity type

Battery structure

Bobbin type

Available terminations

-/P axialpins



-T/PT2 radial pins



-/PT/TP polarized tabs



Main applications:





Automatic meter reading



Memory backup for computers



Alarms and security systems



Radio Frequency Identification



Tire Pressure Monitoring System



Metering systems



Tollgate systems



Tracking systems



Remote monitor systems



Business machine

lithium battery A size ER18505 3.6v 3500mah lithium batterylithium battery A size ER18505 3.6v 3500mah lithium battery



lithium battery A size ER18505 3.6v 3500mah lithium battery



For any question,comment or more information,please do not hesitate to contact me.



Skype : ctechsales03



MSN:   sales03 @ctech.net.cn



Email: sales03 @ctech.net.cn



QQ:   2355452584







Warmly Welcom your enquiry.
