Non-waterproof warm white/white color Led SMD5050 lighting bar
Small and light, low power, LED brightness, light uniformity, long life, easy installation, very suitable for the installation of the counter can be widely used in jewelry counter, business showcase, bookcases, Kitchen cabinets, wardrobe and so on.
How to install
Welcome to JJW !
Installation instructions
1.select the appropriate size according to the counter shading plate
2.according to installation method will be shown in the main counter shading plate bonding within the appropriate location (optional groups of Adhesive Bonding, UV or glass adhesive connection.)
3.counter shading plate with 45 degree corner stitching, light bar with soft docking connector (such as the length of the longer, you can peel the soft connection fittings)
4, according to the icon for each power connection strip the length of the layout of power supply, power cable to cross over the line pipe
Accessories matching program
1, Power: DC12V
2, shading plate: the length of the same size counter
3, the soft connection: one for each corner
4, over-ray tube: one for each power
Luminous color and apply to situations
1, Warm White: gold, jade, colored gems
2, natural white: silver, white, amber, clothing, leather goods
3, the cold White: diamonds, crystal, watches
Note
1.can be a single set of connections, and can parallel
2, pay attention to moisture, water
3.light shields installed on the counter from the inside surface of at least 1mm, to prevent heat transfer to the glass case on.
The power supply can be offer :
Power Supply
Input Voltage
Output Voltage
Currency
power
Waterproof Level
How mang meters of bar lighting can be connected
AC220V
DC12V
5A
60W
Non-waterproof
4Meter
AC220V
DC12V
10A
120W
Non-waterproof
8Meter
AC220V
DC12V
20A
250W
Non-waterproof
15Meter
AC220V
DC12V
30A
350W
Non-waterproof
22Meter
AC220V
DC12V
35A
400W
Non-waterproof
25Meter
Case:
