Door Sealing Ceramic Fiber Tape Furnace Sealing Ceramic Wool Tape Refractory Tape

Door Sealing Ceramic Fiber Tape Furnace Sealing Ceramic Wool Tape Refractory Tape thumbnail-1
Door Sealing Ceramic Fiber Tape Furnace Sealing Ceramic Wool Tape Refractory Tape thumbnail-2
Door Sealing Ceramic Fiber Tape Furnace Sealing Ceramic Wool Tape Refractory Tape thumbnail-3
Door Sealing Ceramic Fiber Tape Furnace Sealing Ceramic Wool Tape Refractory Tape thumbnail-4
Door Sealing Ceramic Fiber Tape Furnace Sealing Ceramic Wool Tape Refractory Tape thumbnail-5
Door Sealing Ceramic Fiber Tape Furnace Sealing Ceramic Wool Tape Refractory Tape thumbnail-6
Door Sealing Ceramic Fiber Tape Furnace Sealing Ceramic Wool Tape Refractory Tape photo-1
Door Sealing Ceramic Fiber Tape Furnace Sealing Ceramic Wool Tape Refractory Tape photo-2
Door Sealing Ceramic Fiber Tape Furnace Sealing Ceramic Wool Tape Refractory Tape photo-3
Door Sealing Ceramic Fiber Tape Furnace Sealing Ceramic Wool Tape Refractory Tape photo-4
Door Sealing Ceramic Fiber Tape Furnace Sealing Ceramic Wool Tape Refractory Tape photo-5
Door Sealing Ceramic Fiber Tape Furnace Sealing Ceramic Wool Tape Refractory Tape photo-6
US$ 0.1 - 10 MOQ: 500 Meters
Key Specifications
Get Latest Price
Application:
Heat Insulation
Thickness:
3mm
Width:
75mm
Contact Supplier Request Quote Chat Now
Zibo Yao Xing Fire-Resistant And Heat-Preservation Material Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Application Heat Insulation
Thickness 3mm
Width 75mm
Length 30000
Grade ST (Standard)
Chemical Composition Ai2O3 SiO2
Working Temperature 900C
Fiber Diameter 3nm
Thermal Conductivity 0.075
Shrinkage (1800℉, 3h) <3%
Place of Origin Shandong, China
Brand Name Yao Xing
Model Number YXTX-B1



Product Description



Ceramic Fiber Tape


1.YAO XING 1260 ceramic fiber tape is a cost-effective insulating tape

made from ceramic fiber yarn,

reinforced by a core of glass filament or stainless steel wire

for high strength retention at elevated temperatures, ideal for

most high temperature applications up to 1260°C.
2.YAO XING 1400 tape is a high performance industrial tape

made from zirconia grade ceramic fiber yarn,

reinforced by high temperature alloy wire. It is durable, long-lasting product, ideal for high temperature applications up to 1400°C.

YAO XING tape contains approximately 18% organic fiber

which burns out at high temperatures, causing some smoking and outgassing,

but the tape retains enough strength to be used as effective insulating cloth

at high temperatures.



Characteristics:



1.Excellent high-temperature strength

2.Excellent electric insulation capability

3.Excellent corrosion resistance to acid oil and steam

4.Low thermal conductivity

5.Excellent thermal insulation capability





Applications:



 1.Furnace curtains
 2.Protection against high temperature
 3.High temperature electrical insulation
 4.Cable and fuel line protection
 5.Fire protection
 6.Insulation of industrial chimney



Technical Index:



Classification Temperature

1260

Product

1260 ceramic fiber tape

Code

YXTX-208B1

YXTX-208B2

Service

Temperature(°C)

450

1000

Basic Material

Ceramic fiber

/glass fiber reinforced

Ceramic fiber

/ stainless steel reinforced

Theoretical Density (kg/m3)

600

Specification (mm)

3000×20/50/75/100×2/3

Moisture Content(%)

≤2

Warp Density

56-60piece/10cm

Weft Density

24-30piece/10cm

Organic Content (%)

≤15
