Hydraulic Pile Driver , Pile Hammer for Excavator
- QINGDAO TIANJIN DALIAN NINGBO
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | DLK | |
| Model Number | DLKP08 |
Product Description
hydraulic pile driver for rocks
Introduction
JISAN DLK series hydraulic vibratory hammer is the vibratory driving piling equipment which is popular among a wide variety of foundation projects.
Apart from driving and pulling elements such as sheet piles and pipes, vibratory hammers are also used for soil densifying or vertical drainage, especially suitable for municipal, bridges, cofferdam, building foundation, etc.
With advanced technology, vibratory hammer has advantages of low noise, high efficiency, non-pollution and non-damage to piles, etc.
Advantages
1. Applied to driving and pulling steel plate, cement pile, steel rail, round pipe, steel H-pile, Lasson pile
2. fast conversion between driving and pulling work
3. less tension when pulling piles
4. no damage to the bottom or top of steel plate and steel rail pile
5. No damage to the buildings even working frequently nearby
6. Silent work and short construction period, overcome environmental problems
Parameters
Item / Model | DLKP 08 | DLKP 10 | DLKP 14 | DLKP 20 |
Eccentriv Torque(Nm) | 40 | 50 | 65 | 85 |
Vibration Frequency(Rpm) | 2800 | 2800 | 2800 | 2800 |
Operation Pressure(Bar) | 280 | 280 | 300 | 300 |
Exciting Force(T) | 36 | 45 | 58 | 75 |
Flow Demand(Lpm) | 155 | 168 | 210 | 255 |
Main Body Weight(Kg) | 1450 | 1550 | 1650 | 1800 |
Excavator Weight(T) | 20-24 | 24-32 | 30-40 | 40-45 |
Piling Depth(M) | 5-8 | 7-12 | 7-18 | 20 |
Clip mouth Weight(Kg) | 300/360/350 |
|
|
|
Assistance Arm Weight(Kg) | 450/550/600/750/900 |
|
|
|
Working scene
JISAN DLK series high frequency hydraulic vibratory pile driver is using vibrating pile sinking to drive or extract piles. It is especially suitable for municipal, bridges,cofferdam,building foundation etc.
The standard set of pile hammer include:
- The body of pile driver
- Goose neck (vice arm)
- Clamp;
- Accessories.
JISAN is one of the largest and most professional excavator attachment manufacturer with ten years experience. Our products have been exported to many countries in the world including India,Saudi Arabia, Iran, Brazil, Australia, New Zealand, Southeast Asia, USA and France etc.
With advanced imported CNC Center and strict quality control management, our products have been approved by ISO, CE authority.
1. 7Days*24Hours after-sales service by email and phone
2. Your inquiry will be replied in 24 hours during workdays
3. Our customer-oriented sales and technical team are always at your service
4. OEM Service available
5. Warranty: 14 months warranty for hydraulic breaker, beyond the warranty period, all spare parts offered to you with our cost price (not including freight).
6. Our Trade Assurance can guarantee your benefits
If you have any questions, please contact me by below ways:
Mr. Scott Ning
Mobile: 0086-18615951533
Skype: scott5650
Website:
