Horizontal Lathe Parameter
It can machine inner circle, outer circle, and end and head surface, taper surface. Gap lathe can process the deformation parts. Function is including the drilling and reaming. Metric, inch, diametrical pitch, module thread The bed is made of high-grade cast iron, the guide way is super audio frequency quenching.
Machine Features
Spindle nose: C6-type (No D-type spindle nose)
Chucktype: Direct-coupled;
New improved direct-coupled 3-jaw, 4-jaw chuck;
Guide rail width: 394mm;
Guide rail hardness: HRC50,Depth 1.5mm
Max load capacity between two centers: 500kg;
Provide left and right wheel,
Apron with rapid shift handle in longitudinal and cross direction;
Special indication is required iftailstock sleeve is with a scale;
Mechanical clutch is used for such lathe. No foot brake, No electrical cabinet
Direct-coupled chuck;
Specifications |
Unit |
CDE6250Ax750 |
CDE6250Ax1000 |
CDE6250Ax1500 |
Max. swing over bed |
mm |
500 |
500 |
500 |
Max. swing over carriage |
mm |
290 |
290 |
290 |
Max. swing over gap |
mm |
760 |
760 |
760 |
Width of guide way |
mm |
394 |
394 |
394 |
Dia. of spindle bore |
mm |
52 |
52 |
52 |
Distance between centers |
mm |
750 |
1000 |
1500 |
Taper of center sleeve |
|
Morse No.6 |
Morse No.6 |
Morse No.6 |
Spindle speed |
rpm |
11~1400/22speeds |
11~1400/22speeds |
11~1400/22speeds |
Longitudinal feed |
mm/rev |
0.035-2.842 |
0.035-2.842 |
0.035-2.842 |
Cross feed |
mm/rev |
0.009-0.804 |
0.009-0.804 |
0.009-0.804 |
Metric thread |
mm |
0.5-240(66) |
0.5-240(66) |
0.5-240(66) |
Inch thread |
tpi |
80-1/4(49) |
80-1/4(49) |
80-1/4(49) |
Module thread |
mm |
0.25-120(57) |
0.25-120(57) |
0.25-120(57) |
Diametrical pitch thread |
DP |
160-7-16 (50) |
160-7-16(50) |
160-7-16(50) |
Section of tool shank |
mm |
25×25 |
25×25 |
25×25 |
Travel of top slide |
mm |
150 |
150 |
150 |
Max. travel of cross slide |
mm |
348 |
348 |
348 |
Pitch of longitudinal lead screw |
mm |
12 |
12 |
12 |
Travel of tailstock center sleeve |
mm |
150 |
150 |
150 |
Diameter of tailstock center sleeve |
mm |
75 |
75 |
75 |
Taper of tailstock center sleeve |
Morse |
Morse No.5 |
Morse No.5 |
Morse No.5 |
Main motor power |
kW |
7.5kW(50Hz)/5.5kW(60Hz) |
7.5kW(50Hz)/5.5kW(60Hz) |
7.5kW(50Hz)/5.5kW(60Hz) |
Wooden case/Steel pallet |
mm |
2740×1150×1900 2580×1120×1610 |
2950×1150×1900 2830×1120×1610 |
3450×1150×1900 3330×1120×1610 |
Gross/net weight |
kg |
2665/1970 |
2765/2070 |
2855/2120 |
