Home > Consumer Electronics > Washing & Drying Machine & Parts > Washing Machine Parts > Electric Motor Washing Motor

Electric Motor Washing Motor

US$ 1 - 10 MOQ: 500 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

YCB

Model Number:

Contact Supplier Request Quote Chat Now

Zhejiang Yongchang Electric Corporation

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI CHINA

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name YCB

Model Number XD

Specifications

washing motora smoothing in operated
fast startup
long work time
smooth running
high efficiency and low noise

1,Specification

The motors can be customized according to the customers need with different Voltage,Frequency ,etc.

Shape and the size of installation:

Code	A	B	C	D	L1	L2	L3	L4	L5
Size	11.5	Φ 12	10	12.5	74	63	89	137	15
	11.5	Φ 12	15	17.5	74	67	89	141	15
	11.5	Φ 12	12	14.5	74	63	89	137	15

2,Performance parameters

The specification of our general products as below:

Model	Voltage(V)	Frequency(Hz)	capacitance(uF)	Insulation class	Rated speed(r/min)	Output power(W)	efficiency(%)	Starting torque(N.m)	Greatest torque(N.m)
XD-180	220	50	14	E	1350	180	52	1.4	2
XD-150	220	50	13	E	1350	150	51	1.3	1.8
XD-135	220	50	11	E	1350	135	50	1.1	1.7
XD-180	110	60	50	E	1620	180	52	1.4	2
XD-150	110	60	48	E	1620	150	51	1.3	1.8
XD-135	110	60	46	E	1620	135	50	1.1	1.7

3,Raw Material

Silicon Steel for Rotor and Stator

Steel for Shaft

Iron or Aluminum Cover

Copper or Aluminum enameled wire

4,Manufacturing process

5,Packing detail

4 pcs one carton with foam

one container (20GP)containing 6000pcs

One pallet 252 pcs for spin motor.

One pallet 216 pcs for wash motor.

One container (20GP)containing 20 pallet

Can be customized according to customer’s requirement packaging.

6,Why choose us

1) Safe and reliable, low noise, good starting, long life, etc.

2) All our products pass the CE/CCC/ROHS/SGS/ISO9001/TUV/BV

2) This motor can be designed and produced according to your request.

3) We will send you some samples for your further inspecting.

4) We have more detailed specifications.If you are interested in, please mail us.

7,Certification,Patent,ISO

All our products passed the CE/CCC/ROHS/SGS/ISO9001:

If you have further questions , please mail us ! We will meet your requirements.

Sales Department

Tel:86-188 5721 5000

Email:admin@

Skype:hzbryant

Web:

Our company was established in 1994,it occupied a land area of 20280 square meters and specialized in micro-motors manufacturing. Owing good service,variety of high quality products and competitive price. We ensure efficient delivery,enjoying a good reputation among our customers.
