Help CenterBRASS SWING CHECK VALVE - MBV BRAND
US$ 500.00 - 500.00
MOQ: 2 Pallets
Key Specifications
Get Latest Price
Structure:
Check
Pressure:
Medium Pressure
Power:
Hydraulic
Payment & Shipping
Payment Methods:
Port of Shipment:
Hai Phong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
BRASS SWING CHECK VALVE - MI BRANDUS$ 500.00 - 500.00MOQ: 2 Pallets -
BRASS SWING CHECK VALVE FOR WATER FROM VIET NAM 12-10-15US$ 500.00 - 500.00MOQ: 2 Pallets
-
BRASS SWING CHECK VALVE WITH BRASS SEAT FOR WATER SYSTEM COMPETITIVE PRICEUS$ 1430.00 - 1430.00MOQ: 1000 Units
-
BRASS SWING CHECK VALVE DN 15 HIGH QUALITY WITH COMPETITIVE PRICEUS$ 1.32 - 1.82MOQ: 1 Unit
-
BRASS SWING CHECK VALVE DN 20 HIGH QUALITY WITH COMPETITIVE PRICEUS$ 1.16 - 1.66MOQ: 1 Unit
Structure
Check
Pressure
Medium Pressure
Power
Hydraulic
Material
Brass
Temperature of Media
Medium Temperature
Media
Water
Place of Origin
Hanoi, Vietnam
Application
General
SPECIFICATION
Brass swing check valve, With Brass seat, Screwed ends.
BS Standard
Max. working pressure: 10 Bar
Max. working temperature: 120oC
MATERIAL
NO PARTS MATERIAL
1 |
Body |
Brass |
2 |
Swing disc |
Brass |
3 |
Pin |
Brass rod |
4 |
Bonnet |
Brass |
5 |
Lock screw |
Brass rod |
DIMENSION
| Valve size | 1/2 15 |
3/4 20 |
1 25 |
1.1/4 32 |
1.1/2 40 |
2 50 |
2.1/2 65 |
3 80 |
4 100 |
| ØA (mm) | 13 | 17 | 23 | 28 | 32 | 44 | 56 | 66 | 86 |
| B (mm) | 40 | 45.5 | 54 | 66 | 75 | 88 | 102 | 122 | 134 |
| C (mm) | 9 | 9 | 10.5 | 12 | 13.5 | 14 | 16 | 18 | 20 |
| Sw (mm) | 24.5 | 30 | 37 | 47 | 53 | 65 | 83 | 94 | 122 |
| Weight (g) | 95 | 130 | 205 | 350 | 460 | 770 | 1220 | 1810 | 3200 |
| Pcs / box | 12 | 10 | 8 | 6 | 4 | 2 | 2 | 1 | 1 |
