Minh Hoa is seeking the oppotunities to co-operate with any enterprise in the water supply industry who is in need of machining brass fittings and import common brass products such as valves, garden taps. Here are some information of our zinc alloy garden tap MBV brand product that you might need.
SPECIFICATION
Garden taps, Screwed ends, Zinc plated.
Cobalt blue colour lever handle
BS Standard threads.
Max. working pressure: 10 bar
Max. working temperature: 100oC
MATERIAL
NO. PARTS MATERIAL
1 |
Body |
Zinc alloy |
2 |
Nut |
Brass |
3 |
Seats |
PTFE |
4 |
Ball |
Cast iron |
5 |
Head pipe |
Zinc alloy |
6 |
O - ring |
NBR |
7 |
Deivide head |
HDPE |
8 |
Lock nut |
Galvanized steel |
9 |
Wheel nut |
Galvanized steel |
10 |
Lever handle |
Stainless steel |
| 11 | O - ring | PTFE |
| 12 | Stem | Galvanized stell |
DIMENSION
| Size | inch | 1/2 | 3/4 |
| mm | 15 | 20 | |
| A (mm) | 92 | 92 | |
| B (mm) | 38.5 | 46 | |
| C (mm) | 40.5 | 41 | |
| ØD (mm) | 8 | 10 | |
| E (mm) | 37.5 | 40.5 | |
| F (mm) | 75 | 86.5 | |
| ØG (mm) | 15 | 20 | |
| H (mm) | 9.5 | 11 | |
| Sw (mm) | 21 | 26.5 | |
| Weight (g) | 132 | 170 | |
| Pcs / box | 10 | 10 |
If you wonder about our manufacturing capcacity, here is a glance of our profuse human& machinery resource to serve your need. We have 54 hot forging machines for creating valve body and valve parts and 7 cold forging machine to handle bavia. Then those valve parts will be machining with more than 100 machining machines, and nearly 30 semi-automatic machines , and many other machines....
Here is a glance of our machines for creating zinc alloy garden tap
Forging machine to make valve parts and body
Medium forging machine with 40-160 tons of force
Large forging machine with 325 tons of force specialized to produce large size valves
Then our machining machines
NC lathe machines
NC lathe machine
Automatic lathe machine
And to create good zinc alloy garden tap products , we need not only sufficient machines but also high quality brass pieces. And all the brass material for export products - MIHA brand is high quality brass rod imported from Malaysia. And we also adapt a strictly inspection procedure for each batch of output brass parts with a Germany spectrometer - Spectromax.
