1. Why we choose Beier 90W/95W/100W Mono solar panel/module?
1. Specialized in producing solar panels for many years with good reputation.
2. Procured by many provincial and municipal government as long-term partners
3. Exported to more than 30 countries and area as top brand
4. Approved by domestic and international quality system certification
5. More than 90% power output guarantee Within 10 years, and within 20 years, more than 80% power output, 5 years product warranty.
6. Widely used in solar led street lights, various types of grid and off-grid PV systems.
If you have any question, please feel free to contact us! (skype: angelzhengxx)
2. Technical Specification of 90W/95W/100W Mono solar panel/module
| Type | BEM90 | BEM95 | BEM100 |
| Maximum Power (W) | 90W | 95W | 100W |
| Optimum Power Voltage (Vmp) | 18.70V | 18.72V | 18.74V |
| Open Circuit Voltage(Voc) | 22.30V | 22.60V | 22.90V |
| Optimum Operating Current (Imp) | 4.82A | 5.08A | 5.18A |
| Short Circuit Current (Isc) | 5.36A | 5.46A | 5.56A |
| Cell Efficiency(%) | 16.8% | 16.89% | 17.78% |
| Power Tolerance | -3/+3 % | ||
| Temperature Coefficient | Pm(%)/ °C | -0.47%/ °C | |
| Voc(%)/ °C | -0.34%/ °C | ||
| Isc(%)/ °C | 0.045%/ °C | ||
| Standard Test Conditions | Irradiance 1000 W/m2, module temperature 25 °C, AM=1.5 | ||
| Size of Cell | 125*125mm, 36pcs(4*9) | ||
| Size of Module | 1190*540*30mm | ||
| Weight | 7.8kg | ||
| Temperature Range | -40 °C to +85 °C | ||
| Surface MaximumLoad Capacity(Pa) | 5400 | ||
| Allowable Hail Load | 25mm ice-ball with velocity of 23m/s | ||
Packing details of Beier 90W/95W/100W Mono solar panel/module
Company Information
Jiangsu Beier Lighting Electrical Appliance Co., Ltd is situated at Yangzhou, regarded as historic & cultural famous city in China. Since its foundation in 1993, products include five series, such as street lamp, LED street lamp, solar street lamp, landscaping brightening, small-scaled solar generation station. The company holds six production lines, such as high-rate SMT, hydraulic interlink (1000t) bending machine (16m long), color powder electrostatic painting, LED light fixture, light fixture fine processing (CNC) and solar panel.
This company holds a batch of senior R&D team, and has over twenty sets of national patents. Beier has successively developed high-end high-power LED special light fixture such as Hubble, Armstrong, Mars-500, Administration version, little golf, Beier No.1, Beier No.2, Gold Beier , Star of Administration.
Light up dream by science and technology, and make Beier navigate after flying sail of energy save!
FAQ
Q:Where your 90W/95W/100W Mono solar panel/module usually use?
A:1. for streetlight, solar lamp, garden lamp use
2. For water proof, drinking water, irrigate solar water pump.
3. portable solar system for house & camping.
4. For house, factory or electric generation, on grid electricity use
Q:Are you manufacturer or trading company?
A: We are solar panel manufacturer, 300pcs-500pcs per day. Mono solar panel ranges from 30W to 280W and Poly solar panel range from 30W-255W.
Q:How many employees in your company?
A:We have about 200-300 employees including 10 R&D engineers, 30 sales and 200 production line workers.
Q:Required mainly certificates?
A:Our products are certificated by CCC,CE ,CQC, etc.
Q:Your main export market?
A:The main market of our products is South-East Asia, Mid-East, Africa, Europe and Latin America.
If you any question, please contact us freely!
Contact person: Angel Zheng
Email: angel(@)
SKYPE:angelzhengxx
