smt solder paste printing machine for Electronic Appliances Production Line
- SHENZHEN/HONGKONG
- L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | chuangwei | |
| Model Number | CWXG-1A |
Product Description
smt solder paste printing machine for Electronic Appliances Production Line
Specifications
1.inline smt solder paste printing machine
2.printing machine for PCBA
lder paste printing
4.high precise printer
inline SMT solder paste printing machine for electronics factory PCB assembly
Feature of our pcb printer machine
1.structure based on the principle of mechanical design, not easy to deform, front and rear doors with cylinder style structure, top cover with humanized design, can be easily opened with only 3kg of strength. The entire equipment with scientific,safe and labor-saving design, and also according to the principles of physics and chemicals, to achieve high efficiency, energy saving and environment protection.
2.The machine according to the aesthetic design, with nice shape and fluency lines. electrostatic sprayed surface makes firm coating, bright color and excellent appearance
Screen Frames | Min Size | 470X380mm |
| Max Size | 737X737mm |
| Thickness | 25~40mm |
PCB Min Size | 50X50mm | |
PCB Max Size | 400X340mm | |
PCB Thickness | 0.4~5mm | |
PCB Warpage | <1% | |
Transport Height | 900±40mm | |
Transport Direction | Left-Right;Right-Left;Left-Left;Right-Right | |
Transport Speed | Max 1500mm/S Programmable | |
Board Location | Support System | Magnetic Pin/Up-down table adjusted |
| Clamping System | side clamping,vacuum nozzle |
Print head | Two independent motorised printheads | |
Squeegee Speed | 6~200mm/sec | |
Squeegee Pressure | 0~15Kg | |
Squeegee Angle | 60°(Standard )/55°/45° | |
Squeegee Type | Stainless steel(Standard), plastic | |
Stencil Separation Speed | 0.1~20mm/sec Programmable | |
Cleaning System | Dry,Wet,Vacuum (Programmable) | |
Table Adjustment ranges | X:±4mm;Y:±6mm;θ:±2° | |
Specifications of the Machine | ||
Repeat Position Accuracy | ±0.008mm | |
Printing Accuracy | ±0.02mm | |
Cycle Time | <8s (Exclude Printing & Cleaning) | |
Product Changeover | <5Min | |
Air Required | 4.5~6Kg/cm2 | |
Power Input | AC:220±10%,50/60HZ 1Φ 3KW | |
Control Method | PC Control | |
Machine Dimensions | 1140(L)X1360(W)X1560(H)mm | |
Machine Weight | Approx:1000Kg | |
