quality pcb dealing handling machine
quality pcb dealing handling machine features:
1.The machine was designed to separate pre-scored PCB carefully, without bending and tension stress.
2.Even sensitive SMD-Components like ceramic capacitors, will not be damaged by the separating process, or thin board even to 0.3mm can be worked safely.
3.Separating process without vibrations
4.PCB separating control method is by pneumatic-driven and electromagnetic valve
5.PCB separating operation is that operator stamps the foot pedal to separate PCB
6.Highest components near the v groove of PCB can be up to 50mm
7.Gap for insertion of PCB can be easy to adjust
quality pcb dealing handling machine
1.Max. PCB separating length is unlimited
ucing bending and tension stress
3. ruler blade knife pcb depanelizer Safety use, easy operation
4.Separating process without vibrations
quality pcb dealing handling machine specifications:
Model |
CWVC-3 |
Max. PCB separating length |
unlimited |
PCB separating thickness |
0.3-3.5mm |
PCB separating speed |
1~2 times/second |
PCB separator machine size |
780x500x620mm |
PCB separator machine weight |
185Kg |
quality pcb dealing handling machine Our unique service:
1. One year warranty for the machines
2. Oversea training and techincal support program
3. professional R&D team to meet sepcial requirments
quality pcb dealing handling machine Certificate:
quality pcb dealing handling machineCustomers:
