Dingli Vertical Shaft Making Machine for Artificial Sand Rock

Specifications

Introduction------ Vertical shaft making machine for artificial sand rock :

• Based on the using situation of sand making machine in China and combined the suggestion and requirement of many clients in sand making industry,
• our engineers under the requirement of high impact strength and biting speed and such character in sand making process develop this ZSJ double rotor hammer sand making machine.

Working principle------ Vertical shaft making machine for artificial sand rock :

• In working proecess,two rotors revolve reversely.The materials entering the crushing space will be crushed by the hammer in the first rotor and gain a kinetic energy,
• and then they will be thrown to the second rotor.Because the revolving direction of second rotor is opposite to the direction of materials flying to
• the speed of the second rotor biting is amount to the summation of the speed of two rotors.The materials will be output throug the grid section after the revolving crush.

Advantages------ Vertical shaft making machine for artificial sand rock :

• Gain high biting kinetic engergy with low revolving speed,so the wear and tear will be lessened.
• This machine characters simple structure,stable work,high reduction ratio,low energy and so on.It gain much reputation for us as soon as it is offered.

Main Parameters------ Vertical shaft making machine for artificial sand rock :

• Type	ZSJ-0808
  Input Size	<150mm
  Output Size	0-10mm
  Power Rating	2x55KW
  Capacity	20-50t/h
  Weight	5.85t
  Dimensions	5500x1843x160mm(L*W*H)
