24.125ghz microwave sensor for automatic door opening(YS102)

FOB Price

USD $1 - $20 / Piece

10 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1.Germany innosent detecting chip, 24.125GHZ.

2.Electric filter provide a good capacity of resisting disturbance from raining, wind, lighting and so on.

3.Safe, beautiful, economic, comfortable.

24.125ghz microwave sensor for automatic door opening(YS102)
Approval	CE & ISO9001
Power supply	AC/DC 12-36V
Current consumption	Static Current 45mA Action Current 105mA
Environmen tal temperature	-20℃ ~ +60℃
Environmen tal humidity	0-90%, without condensation
Wave form	X-Band 24.174 GHZ
Out put	<=20dBm
Relay output	N.O.-point output (Relay)
Maximum voltage	48V AC/DC
Maximum current	0.5A AC/ 1.0A DC
Minimum switching power	1 mA
The largest power switch	55VA /24W
Weight	220g
Protection level	IP 54
Size	1316146mm(LWH)

Synopsis

Application
