S-60-12 60W 12V DC Switching Power Supply

S-60-12 60W 12V DC Switching Power Supply thumbnail-1
S-60-12 60W 12V DC Switching Power Supply photo-1
US$ 1 - 10 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
JUNXELE
Model Number:
S-60-12 60W 12V
Contact Supplier Request Quote Chat Now
Wenzhou Junxiong Electrical Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name JUNXELE
Model Number S-60-12 60W 12V
Output Power Other, 15-500W
Output Type Single
Input Voltage Other, 85~132VAC/170~264VAC selected by switch 47~63Hz; 240~370VDC
Output Voltage 12V
Output Frequency 47-63HZ
Output Current 5A

S-60-12 60W 12V    DC switching power supply



1. Low price and high reliable.



2. 105 `C output capacitor



3. AC input power suitable for the world



4. High efficiency and how operation temperature.



5. Soft-start current can reduce the AC input impact effecticly.



6. With short-circuit and overload protection.



7. Compact size, light weight.



8. 100% full-load buming test.



9. installed with EMI filter, minmum wave.





What is the story of JUNXELE ?





If Ask me, What is the Most Important switchgear in the World? Children will Tell You the Truth. in a Poor Village, Innocent Children no Education, no Happiness and no Hope. However, JUNXELE Brings new Power and Love There. After That,Sunshine Smile is Always around Children. They See Hope for Everything and Know How to Deliver Love with Lightness.







JUNXELE Brings Brightness, Warmness and Hope. Let me Know What is LOVE!!!







Product Description

 S-60-12 60W 12V DC switching power supply

S-60-12 60W 12V DC switching power supply

Model Specification

S-60-5V

S-60-12V

S-60-15V

S-60-24V

DC Output Voltage

5V

12V

15V

24V

Iutput Voltage Error

± 2%

± 1%

± 1%

± 1%

Rated Output Current

12A

5A

4A

2.5A

Output Current Range

0-12A

0-5A

0-4A

0-2.5A

Tripple and Noise

100mVp-p

120mVp-p

120mVp-p

120mVp-p

Iniet Stability

± 0.5%

± 0.5%

± 0.5%

± 0.5%

Tolerance Voltage

± 1%

± 0.5%

± 0.5%

± 0.5%

DC Output Power

60W

60W

60W

60W

Efficiency

73%

76%

77%

79%

Adjustable Range for DC Voltage

`+10, -5%

± 10%

± 10%

± 10%

AC Input Voltage Range

85~132VAC/170~264VAC selected by switch 47~63Hz; 240~370VDC

Input Current

2A/115V 1A/230V

AC Inrush Current

Cold-Start Current: 30A/115V, 60A/230V

Leakage Current

<1mA/240VAC

Overload Protection

105%~150% Type: Cut Output, Reset: Auto Recovery

Over Voltage Protection

…………

High Temperature Protection

…………

Temperature Coefficient

± 0.03% /°C (0~50°C)

Start, Rise, Hold time

800ms, 50ms, 10ms, /115VAC 300ms, 50ms, 80ms, /230VAC

Vibration

10~500Hz, 2G 10min,/1cycle, a total of 60 minutes, Each axes

Withstand Voltage

Between Input and Output: 1.5KVAC, Input and Shell: 1.5KVAC, Output and Shell: 0.5KVAC

Isolation Resistance

Input and Output Intermal: Input and Enclosute, Output and Enclosure: 500VDC/100M Ohms

Working Temperature and Humidity

`-10°C~+60°C (Refer to Output Derating Cutve), 20%~90%RH

Storage Temperature and Humidity

`20°C~+85°C, 10%~95%RH

Overall Dimension

159*98*38mm

Weight

0.56kgs

Safety Standards

Meet UL 1012 requirement (Not apply for the mark)

EMC Standards

Meet FCC Part 15J Conduction class B
