Help CenterAircraft Tow Tractor T150
Related Products
Specifications
Aircraft tow tractor T1501.Gross Vehicle Weight 12t up to 15t
2.Overall 5m(L)*2.2m(W)*1.8m(H)
3.Engine Deutz TCD2012/L04
Aircraft tow tractor T150
Operating Performance
Drawbar Pull 120kN
Drive Speed 27km/hr
Turning Radius 5m, 2 wheels steering, outside
3.3m, 4 wheels steering, outside
Weight and Dimensions
Gross Vehicle Weight 12t up to 15t
Overall Dimension 5m(L)×2.2m(W)×1.8m(H)
Wheelbase 2.15m
Ground Clearance 200mm
Standard Equipment
Engine Deutz TCD2012/L04 86kw
Transmission Power shift with torque converter, 4 speed forward/3 speed reverse
Axles 4-wheels drive, front axle leaf spring with shock absorber, rear axle rigid mounted
Tires 300-15
Steering Load sensing hydraulic power steering, all wheels steering
Brakes Dual circuit hydraulic wet disc brake, all wheels
Parking Brake Spring loaded with hydraulic release
Electrical 24Volt DC
Cab Airconditioned, fully adjustable air suspension seat, adjustable air vents, tinted windows opening side, intermittent two-speed windshield wiper and washer.
Lights cab interior, front, rear, stop/tail lights, back up lights, front and rear direction indicators, front and rear working lights, flashing beacon
Mirrors left and right main, right auxiliary, rear coupler
Optional Equipment
Fleet manager
360°vision system
Extreme Weather Packages
