BNC male to SMA female RF adaptor connector,BNC plug to SMA jack for CCTV,antenna

Specifications

1.a wide range
2.good quality
3.easier for installation, save time and safer cable connection

    The BNC (Bayonet Neill–Concelman) connector is a miniature quick connect/disconnect radio frequency connector used for coaxial cable. It features two bayonet lugs on the female connector; mating is fully achieved with a quarter turn of the coupling nut. BNC connectors are used with miniature-to-subminiature coaxial cable in radio, television, and other radio-frequency electronic equipment, test instruments, and video signals. The BNC was commonly used with 10BASE2computer networks. BNC connectors are made to match the characteristic impedance of cable at either 50 ohms or 75 ohms. They are usually applied for frequencies below 4 GHz and voltages below 500 volts.

Similar connectors using the bayonet connection principle exist, and a threaded connector is also available. United States military standard MIL-PRF-39012 entitledConnectors, Coaxial, Radio Frequency, General Specification for (formerly MIL-C-39012) covers the general requirements and tests for radio frequency connectors used with flexible cables and certain other types of coaxial transmission lines in military, aerospace, and spaceflight applications.

Male 50 ohm BNC connector
Type	RF coaxial connector
Production history
Designer	Paul Neill, Carl Concelman, & Octavio M. Salati
Designed	Patented 1951
Manufacturer	Various
General specifications
Diameter	Male:      0.570 in (1.45 cm) Female:  0.436 in (1.11 cm) (outer, typical)
Cable	Coaxial
Passband	Typically 0–4 GHz
