Mini Skid Steer Loader XD380

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Brand Name:

Model Number:

XD380

Taian Modern Heavy Industries Technology Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao or others

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name XD

Model Number XD380

Place of Origin Shandong, China

Type Skid Steer Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 2206*1033*1205mm

Rated Load 280kg

Specifications

mini skid steer loader
1.B&S3854 engine(21HP)
2.load:280kg,bucket:0.15M3
3.15attachment,joystick,4tyres
4.wheeled or tracked

mini skid steer loader(Model XD380) for garden or farm cleaning.

1.wheeled or tracked for different needs

2.engine:B&S3854,Kohler gas engine with EPA certification, EURO II displacement.

3.optional: four kinds of tires, fifteen kinds of tools,hydraulic servo handle

4.one year warranty

5.the black cover in top front is good for heat emission.

6.wheeled or tracked for needs

Model	XD380
Engine Model	Briggs&Stratton 3854 gas
Rated Power	20HP/ 15.5kw
Performance
Hydraulic pumps	2 pumps
Relief pressure(drive)	170bar
Relief pressure(aux )	170bar
Attachment flow	25 l/min
Travel Speed	0-5.5Km/h
Rate lift capacity
Rate lift capacity	SWL:325kg
Rate lift capacity	MWL:375kg
Auxiliary hydraulic outlets	3 or 5
Dimensions
Overall length	1752mm (without bucket)
Overall length	2206mm (With bucket)
Overall width	1150mm
Overall height	1233mm
Max operating height	2143mm
Turning radius with 4-in-1bucket	1307mm
Angle of departure	11
Wheel base	636mm
Ground clearance	118mm
Dump height Std bucket	1473mm
Dump reach	348mm
Height to hinge pin	1880mm
Machine width	1160mm
Hydraulic reservoir capacity	27L
Machine mass	920kg
