Hydraulic Rock Breaker

Hydraulic Rock Breaker photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
XD
Model Number:
XD380
Payment & Shipping
Payment Methods:
Port of Shipment:
as your request
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Brand Name XD
Model Number XD380
Place of Origin China
Type Skid Steer Loader
Moving Type Wheel Loader
Dimension(Long * Breadth * High) 2.2*1.1*1.2m
Rated Load 280kg

Specifications

hydraulic rock breaker
1.B&S 21HP engine
2.max working pressure:110Bar
3.oil flow:25-35l/min
ing frequency:10-13Hz

Hydraulic rock Breaker for breaking rocks,concrete.

1.engine:21HP or 23HP

2.wheeled or tracked for needs

3.max working pressure:110Bar

4.max oil flow: 25-35l/min

Model

XD380

Engine Model

B&S 3854

Rated Power

20HP

working frequency

10-13Hz

max oil flow

25-35l/min

Operating Weight

940KG

Engine Displacement

627ML

System Pressure

17mpa

Bucket Breakout Force ,Bucket Cylinder

550KN

Breakout Force,Lift Cylinder

375KN

Tipping Load

325KG

Max lifting force

375KG

Grade Ability

8

Fuel Tank Capacity

21L

OIL Tank Capacity

27L

Max.Travel Speed

5.5Km/h

 Solid tires

16*6-8

Dimension(L*W*H)

2206*1033*1205mm(loader with solid tires)

Remarks:

1. you can choose hydraulic pilot control , crawler.

2.optional tires: lawn tire(18*9.5-8), engineering tire(18*9.5-8), narrow tire(5.00-8).

3.optional attachments:fork,auger, angle blade,grapple,breaker,lawn mover, trencher, snow blower, backhoe ,tiller,mixer,leveler,ripper,4-in-1 bucket etc.

4.4kinds of tires,15kinds of attachments are optional to make this mini loader multifunctional.
