Inline screen changer Percolator
Applications:
1. Suitable for all of the plastic such as granulation (master batch, cable materials, functional master batch, synthetic granulation, recycling granulation, etc.).
2. Sheet.
3. Plate.
4. Pipe.
5. Laminating.
6. Small blown film.
7. Wire.
8. Cable.
Performance characteristic:
1. It is designed with special sealing system.
2. Matched with extruders of different specification.
3. It is applicable to process with most polymers.
4. At high output.
5. Screen changing time is within 2 seconds.
6. Screening area covers from Φ30 to Φ250.
7. With highly precise design.
8. The screen has very good abrasive resistant.
9. High pressure performance.
10. It ensures large effective filtering area and enhance filtering effect.
11. It works well even under the high temperature of 300 and high pressure of 25Mpa -50Mpa.
Technical Data:
Type |
ScreenDm(mm) |
Heating Power(Kw) |
Pressure(Mpa) |
Output(Kg/h) |
DHB-70 |
Φ70 |
4 |
≤50 |
60-250 |
DHB-100 |
Φ100 |
6 |
≤50 |
110-400 |
DHB-120 |
Φ120 |
8 |
≤50 |
140-550 |
DHB-150 |
Φ150 |
9 |
≤50 |
200-800 |
DHB-200 |
Φ200 |
12 |
≤50 |
400-1200 |
