Help CenterSDH System Single Channel Pre-Amplifier
Related Products
-
GE OEO Optical-Electrical-Optical Fiber Optical AmplifierNegotiableMOQ: 1 Pair -
10G Optical-Electrical-Optical OEO AmplifierNegotiableMOQ: 1 Pair
-
Optical Amplifier Erbium Doped Fiber Amplifier EDFANegotiableMOQ: 1 Unit
-
EDFA Erbium-doped Fiber Optical Amplifier for SDH NetworkNegotiableMOQ: 1 Unit
-
Single Channel Fiber Optic Amplifier EDFA for SDH SystemNegotiableMOQ: 1 Unit
SDH Rackmounted EDFA
Features:
- Wide input power range
- Output power tunable
- Low NF
- RS-232/SNMP/RS485 network interface
- Remote monitor
- Dual power supply
Applications:
- IP ATM SDH Network
Operating Parameters
1. Booster Amplifier
Parameters |
Min |
Type |
Max |
Units |
|
Operating Wavelength |
1530 |
1550 |
1565 |
nm |
|
Input Power |
2.5G or Below |
-6 |
|
4 |
dBm |
10G |
-10 |
|
4 |
dBm |
|
Output Power |
|
|
19 |
dBm |
|
Output Tunable Range |
|
|
6 |
dBm |
|
Noise Figure |
|
5 |
|
dB |
|
Input/Output Isolation |
30 |
|
|
dB |
|
Input/Output Return Loss |
45 |
|
|
dB |
|
Voltage |
Rack Mount: -48V DC Module Type: +5V DC |
||||
Dimension |
Rack Mount: (W×L×H)482.6×200×43.6 Module Type: (W×L×H)150×125×20 |
mm |
|||
2. Pre-amplifier(With OTF or Fixed Filter)
Parameters |
Min |
Type |
Max |
Units |
|
Operating Wavelength |
Tunable Filter |
1530 |
|
1565 |
nm |
Fixed Filter |
|
1550.12 |
|
|
|
Input Power |
-47 |
|
-15 |
dBm |
|
Output Power |
-7 |
|
0 |
dBm |
|
Output Tunable Range |
|
|
6 |
dBm |
|
Noise Figure |
|
4.5 |
|
dB |
|
Input/Output Isolation |
30 |
|
|
dB |
|
Input/Output Return Loss |
45 |
|
|
dB |
|
Voltage |
Rack Mount: -48V DC Module Type: +5V DC |
||||
Dimension |
Rack Mount: (W×L×H)482.6×200×43.6 Rack Mount:(W×L×H)482.6×200×43.6 |
mm |
|||
