Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > High Performance DWDM System

High Performance DWDM System

Name: High Performance DWDM System
Brand: Billioncom
SKU: 101993115
Availability: InStock

High Performance DWDM System thumbnail-1

High Performance DWDM System thumbnail-2

High Performance DWDM System thumbnail-3

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shanghai, China

Brand Name:

Billioncom

Model Number:

OEO6500

Contact Supplier Request Quote Chat Now

Billioncom Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanghai, China

Brand Name Billioncom

Model Number OEO6500

Product Description

Product Overview:

OEO6500 Platform is an industry-leading optical transport platform, which supports flexible configurations and provides a Transparent Optical Transport Solution based on DWDM technology (Dense Wavelength Division Multiplexing) and CWDM (Coarse Wavelength Division Multiplexing) technology serving with flexibility and cost-efficiency in transporting, multiplexing, switching and protecting high-speed data, storage and video applications. OEO6500 Platform service flexibility in access, backhaul, metro and long-haul networks.

To minimize transport cost and optimize efficiency in all network areas, OEO6500 Platform built with extremely flexible and modular architecture, the capacity of OEO6500 Platform can be expanded without service interruption up to 80 channels at 2.5G and 10G.

OEO6500 platform provides several mechanisms and protection levels in the optical layer, as well as various models of EDFA (Erbium Doped Fiber Amplifier) and Raman Optical Amplifiers which are able to extend terrestrial links distances up to 30km, 50km, 80km, 100km, 120km and over without intermediate regeneration.

Features & Benefits:

Fixed or reconfigurable optical layer for long-haul, metro and access applications supporting DWDM and CWDM
Support for point-to-point, point-to-multipoint, add/drop, ring and mesh networks applications
Multi-service interfaces including CWDM, DWDM, OLT and WDM-PON
High-density design for smallest footprint and lowest power consumption, resulting in operational cost savings

Modules:

Service Access and Aggregation Sub-System:
- OTU Card: Optical Wavelength Conversion card, converting signal of arbitrary rate (125 Mbit/s–10 Gbit/s) at the client side into standard wavelength optical signal in compliance with G.692.
- TMUX Card: Sub-Rate Multiplexer card, regenerating 2 1.25G service onto 1 2.5G, or regenerating 8 1.25G service onto 1 10G.
- OEO Amplifier Card: Optical-Electricity-Optical (OEO) Amplifier card, 8 wavelength 125M-2.5G, 6 wavelength 125M-10G.
Multiplexer and Demultiplexer Sub-System:
- OMUX Card: Optical Multiplexer and Demultiplexer Card for CWDM and DWDM.
- OADM Card: Optical Add and Drop Multiplexing Card, adding/dropping and multiplexing any adjacent two channels of signals.
EDFA Sub-System:
- EDFA Card: Booster Amplifier (BA), Pre-Amplifier (PA) and In-Line Amplifier (LA) card.
- DCM Card: Dispersion Compensation Card, compensating for the optical signal dispersion accumulated during transmission
OLP Sub-System:
- OLP Card: Optical Line Protection card, 1+1 and 1:1 protection, the protection mode is dual-fed and signal selection and single-end switching.
- OBP Card: Optical Bypass Protection card, single-fiber bypass and dual-fiber bypass with built-in heartbeat detection.

Hardware Architecture

Environmental
- Standard temperature (operating): +5°C to +40°C
- Extended temperature (operating): -33°C to +55°C
- Relative humidity (operating): 5% to 85% (non-condensing)
- Relative humidity (short-term): 5% to 90% (non-condensing)
- Outdoor enclosures for passive components
Power
- Voltage: -36VDC to -72VDC or 120/230VAC
Physical
- Mounting brackets for 19”
Shelf Options
- 1U (active and passive), 2U and 5U

Order Information

Order Information:

Name	Model	Description
OEO6500 Shelf	OEO6500-I	1U and 19-inch wide shelf, 4 horizontal slots with a maximum configuration of 1 control card and 3 line cards
	OEO6500-II	2U and 19-inch wide shelf, 8 horizontal slots with a maximum configuration of 1 control card and 7 line cards
	OEO6500-V	5U high and 19-inch wide shelf, 18 vertical slots with a maximum configuration of 1 control card, 2 power cards and 15 line cards
Management Card	OEO6500-SC	system control card with 2 100M electrical interfaces and 2 100M optical interfaces
Management Card	OEO6500-SCE	system control card with 2 100M electrical interfaces, 2 100M optical interfaces and 1 EI interface
OTU Linecard	OEO6500-2G5	with 8 SFP interfaces, support up to 4 channels 125M-2.5G wavelength conversion with rate 125M-2.5G, provide CDR optional
	OEO6500-10G	with 4 XFP interfaces, support up to 2 channels with rate 10G wavelength conversion, provide CDR optional
	OEO6500-SFP+	with 6 SFP+ interfaces, support up to 3 channels with rate 125M-10G wavelength conversion, support 1+1 inter-board hot backup protection
OMUX Linecard	OEO6500-OMUX-CWDM	up to 18 wavelengths CWDM multiplexer and demultiplexer
	OEO6500-OMUX-DWDM	up to 40 wavelengths DWDM multiplexer and demultiplexer
	OEO6500-OMUX-OADM	2-channel optical add/drop multiplexing
AWG Linecard	OEO6500-AWG-C40	40 channels DWDM multiplexer or demultiplexer using AWG Technology
TMUX Linecard	OEO6500-TMUX-2G5	with 4 1.25G SFP interface and 2 2.5G SFP interface, regenerating 2 1.25G service onto 1 2.5G
TMUX Linecard	OEO6500-TMUX-10G	with 8 1.25G SFP interface and 1 10G XFP interface, regenerating 8 1.25G service onto 1 10G
EDFA Linecard	OEO6500-OA-BA	booster amplifier operates at the transmission side of the link, it is designed to amplify aggregated optical input power for reach extension.
	OEO6500-OA-PA	pre-amplifier operates at the receiving end of an optical link, it is designed for optical amplification to compensate for losses in a demultiplexer located near the optical receiver.
	OEO6500-OA-LA	in-line amplifier operates in the middle of an optical link, it is designed for optical amplification between two network nodes on the main optical link.
SOA Amplifier	OEO6500-SOA	semiconductor optical amplifiers, the wavelength range to be amplified is 1300~1600nm, and the gain is larger than 30dB
SOA Amplifier	OEO6500-OA-40G	increasing the optical power to meet the receiving requirements of monitoring equipment and communications equipment
OLP Linecard	OEO6500-OLP-1+1	1+1 protection, the protection mode is dual-fed and signal selection
	OEO6500-OLP-1:1	1:1 protecction, the protection mode use 2 internal switch to switch the whole traffic from primary to secondary line
	OEO6500-OLP-BP	optical bypass protection
	OEO6500-OLP-BIDI	single fiber bidirectional protection mode
DCM Linecard	OEO6500-DCM	Compensate for the Optical Signal Dispersion
EPON OLT Linecard	OEO6500-OLT	EPON OLT with 4 1000M PON interfaces and 4 uplink GE Combo interfaces
WDM PON Linecard	OEO6500-EWDM	4 EPON OLT interfaces, 4 ONU interfaces, supporting wavelength conversion of 4 channels of EPON signals, as well as transmission of 8 channels of EPON links over single-core fiber
WDM PON Linecard	OEO6500-GWDM	4 GPON OLT interfaces, 4 ONU interfaces, supporting wavelength conversion of 4 channels of GPON signals, as well as transmission of 8 channels of GPON links over single-core fiber
Optical Tap Linecard	OEO6500-OTAP	PLC splitter card, the parameters as mode type (single or multi mode), splitting ratio and splitting channels etc is optional
OEO Amplifier Linecard	OEO6500-GA	8 wavelengths 1.25G OEO Amplifier
OEO Amplifier Linecard	OEO6500-XGA	6 wavelengths 10G OEO Amplifier
GE/FE TAP Linecard	OEO6500-GTAP	mirror of 2 channels of 10/100/1000M data
Optical Switch Unit	OSU6116	dual 1x8 optical switch
Optical Switch Unit	OSU6132	dual 1x16 optical switch
10G Bypass Unit	XSB6104	10GE Smart Bypass device, built-in intelligent detection of heartbeat protocol function
AWG Unit	AWG6140	40 channels DWDM multiplexer or demultiplexer device using AWG Technology
AWG Unit	AWG6148	48 channels DWDM multiplexer or demultiplexer device using AWG Technology
