Customized Tungsten Carbide Plate Tools
- ShangHai/ShenZhen
- T/T Credit Card
You May Like
-
Cemented Carbide Blank Plates,tungsten Carbide Wear Plate,High Quality Carbide Shims for Insert
-
Sintered Carbide Boards HIP,high Quality Hardalloy Plates
-
Hot Sale Zhuzhou Kerui Carbide Panel for Making Metal Cutting Tool
-
Wood Cutter Carbide Tips
-
Carbide Cutter Blade
-
High Quality Carbide Shims for Insert
Product Details
| Place of Origin | Hunan, China | Brand Name | Kerui | |
| Model Number | Various | Alloy Specification | K10,K20,K30,K40 | |
| Particle | 0.5-5.0um |
Product Description
Customized tungsten carbide plate tools
Kerui customized tungsten carbide plate tools,made from 100% virgin tungsten carbide raw materials.It can be used in wide application field. Kerui hard alloy cutting plate have high hardness, good red hardness,excellent wear resistance, High Elasticity Modulus and compressive strength.The chemical properties of ou tungsten carbide plates is stable,also the impact toughness & dialatation coefficient is low. The heat-conducting property and electrical conductivity of tungsten carbide plate is close to iron or iron alloy.
It is a very good material to produce the parts to resist high temperature & corrosion, also it is widely used as wear parts and shielding parts. We provide you high quality tungsten carbide plate which can enhance your productivity and save your cost.
Types of customized tungsten carbide plate tools:
Grade: K10,K20,K30,K40,
Surface: in Blank(unground) finish.
Usage: for cutting general wood, hard wood, and aluminum section bar, brass rod and cast iron.
Blank of customized tungsten carbide plate tools:
High polished customized tungsten carbide plate tools:
Other types of customized tungsten carbide plate tools:
Sizes of customized tungsten carbide plate tools:
unit:mm
Length | width | thickness | Length | width | thickness |
210 | 15 | 3.6 | 40 | 10 | 2 |
210 | 12 | 3.6 | 310 | 30 | 4 |
100 | 8.2 | 8.2 | 310 | 10 | 4 |
92 | 15 | 5 | 100 | 8 | 8 |
90 | 12 | 10 | 210 | 18 | 3.6 |
90 | 10 | 5 | 210 | 20 | 4.2 |
78.5 | 6.5 |
| 210 | 25 | 4.2 |
67 | 15 |
| 38 | 38 | 20 |
63 | 4.2 |
| 60.5 | 15 | 2.4 |
60 | 15 |
| 45 | 36 |
|
56 | 15 |
| 100 | 8 | 4 |
52 | 6.5 |
| 100 | 3 | 3 |
50 | 5 | 5 | 80 | 14.1 | 3 |
50 | 8 |
| 80 | 13.3 | 3 |
Customized design is available.
Grades of customized tungsten carbide plate tools for machinery
| Grade | ISO Grade | WC % | CO % | Grain Size | Density | Rockwell Hardness | Vickers hardness | Bending Strength | Application field | |
| g/cm3 | HRA | HRC | HV | N/mm2 | ||||||
| GB16 | K20 | 92 | 8 | 1.6 | 14.7 | 90 | 76 | 1432 | ≥3500 | silicon steel sheet,upper mould |
| GB22 | K30 | 89 | 11 | 1.6 | 14.3 | 88.5 | 73 | 1250 | ≥3650 | Silicon steel sheet of upper mould, The upper and lower mould of cold-rolled sheet materials |
| GB30 | K40 | 85 | 15 | 1.6 | 14 | 87 | 70.4 | 1100 | ≥3800 | The upper and lower mould of Silicon steel sheet and Cold-rolled sheet. |
| GB40 | K40 | 80 | 20 | 1.2 | 13.7 | 84.5 | 66 | 900 | ≥4200 | The upper and lower mould of silicon steel sheet(it is good choose for thick plate with high pressure resistance) |
| Grade | ISO Grade | WC % | CO % | Grain Size | Density | Rockwell Hardness | Vickers hardness | Bending Strength | Application field | |
| g/cm3 | HRA | HRC | HV | N/mm2 | ||||||
| GB05 | K10 | 94 | 0.8 | 1 | 14.9 | 91.55 | 78.4 | 1600 | ≥3200 | For machining copper,aluminum and non-ferrors metal plate |
| GB06 | K20 | 92 | 0.8 | 1 | 14.7 | 90.5 | 77 | 1500 | ≥3600 | For machinings copper pieces,aluminum pieces etc. |
| GB07 | K40 | 87 | 1 | 1 | 14.3 | 88.5 | 73 | 1250 | ≥3850 | Has widely usage, like for copper pieces,aluminum sheet etc. |
| GB08 | K40 | 85 | 1 | 2 | 14 | 88 | 72.2 | 1200 | ≥4000 | Processing for EI pieces,SPCC/stainless steel sheet etc. |
Product Advantages:
1,high speed tool steel
2,well-distributed carbide
3,good toughness
4,high abrasive resistance and hardness
1. How to make an inquiry?
Firstly, please mention the enquired product clearly in terms of grade, type or drawing with dimension and tolerance, quantity etc. It’s better if you could have a brief introduction of your company.
Secondly, please mention your price terms, e.g. FOB, CIF. For CIF, please name the destination port.
2. What’s your MOQ?
Our MOQ could be 1 piece or 1kg. But the price will be a little bit high when the quantity below
50kg or 2000USD.
3. What’s your delivery time?
For standard types, the delivery time is normally 25-30 days. For nonstandard type or further processed type, the delivery time is 40-45 days. If you need the goods urgently, we could try to push the production and shorten the delivery time.
