Small PIR Motion Sensor Fitting in Ceiling Lamp

PIR  motion sensor/pir sensor/motion sensor

Fitting in Ceiling lamp

Model:SA003T

Specification:
1) Detection range: 90 degrees
2) Detection distance: 6m (max., <24°C)
3) Power source: 220 - 240V/AC, 110 - 130V/AC
4) Power frequency: 50 - 60Hz
5) Rated load: 100W (110-130V/AC)  150W(220-240V/AC)

6) Working temperature: -10°C - +40°C
7) Duration time: 5 - 360s (adjustable)
8) Ambient light: <3Lux~daylight (adjustable)

9)Detection Motion Speed:0.6~1.5m/s

10)Working Humidity:<93%RH

11)Application: Fix in ceiling lamp

Features:
1 Can avoid from unnecessary long-time lighting in public places;
2 Replace the existing wall switch directly;
3 Motion sensor control;
4 The lamp will turn on automatically, when somebody moves into the controller;
5 The lamp will turn off in setting time, when the person leaves from the scope;
6 Be suitable for corridor, factory, hotel, office

We  are a company mainly producing pir motion sensor, microwave sensor, sensor lighting and so on with high quality and competitive price. We also have our own R&D and can make products according your special request or sample you offered.
