Specifications
1.NC studio or DSP control2.Ucancam,Type 3,Artcam software.
3.Water or air cooling system
4.24-hours after-sale service
Ncstudio Control 1325 CNC Router Extension
1. Brief introduction:
This is a cnc woodworking machine and widely used in woden furnitures,wood
doors,,advertisementing billboard, letter mold forming,relief engraving and cutting.
2. CNC router extension picture:
3. Parameters:
Model Name |
CNC-R1325 |
Working Area |
1300*2500*190mm |
Spindle Power |
2.2KW |
Lathe Bed |
cast or welded |
Lathe Table |
Aluminum alloy/PVC |
XYZ guide rail |
Square Rail |
XYZ transmission |
Gear rack |
Cooling system |
Water cooling |
Spindle |
Changzhou |
Inverter |
Rituo or other brands |
Driver |
Leadshine882 |
Working Dictate |
G Code |
Operation Software |
NC Studio |
Typeset Software |
Artcut (English) |
Working Dictate |
G Code |
Processing accuracy |
<0.05mm/300mm |
Max Engraving Speed |
20,000mm/min |
Spindle rotational speed |
6000-24000rpm |
Tool Diameter |
Φ3.175mm,Φ6mm,Φ12.7mm |
Working Voltage |
AC220V/50Hz,380V/60Hz |
Optional Parts |
Dust collecting system |
Vacuum table with air pump | |
Mist sprayer and flume | |
Rotary device with Dia 80mm/100mm/200mm |
4. Features:
1) Imported linear square guide rail ensures high accuracy and maximum work load-bearing.
2) Function of continuous working at stop point by power failure.
3) High power spindle, low noise, guarantees long time mass processing.
5. Main parts picture:
1) optional DSP handle control
2) optional Italy HSD air cooling spindle
3) optional vacuum table
6. Samples pictures:
7. Packing details:
8.Factory show:
9. Before and after service:
1) One year warranty for machine, free maintenance service within this period.
2) 24 hours online answer via skype, email.
3) Free training in our factory.
