High Efficiency Practical HFU-3A tunnel boring machine
General Introduction------drilling machines in tunnel
HFD-3 drill rig is mainly applied in the fields of coal, geology, metallurgy and engineering. It is used for drilling large dia. gas suction hole in mines, gallery as well as coal mine, water injection hole, and big dia. horizontal hole. It can meet the big dia. roller drilling, hard tungsten-carbide drilling and percussive-rotary drilling.
Main Features ------drilling machines in tunnel
1. It is separate in structure, small in size, light in weight, flexible in movement and convenient in operation.
2. The hydraulic pump is driven by explosion-proof electric motor through operating system, then the hydraulic pump enforces hydraulic motor to make drill head rotate, and at the same time, the movement of drill head is realized by oil cylinder & chain double speed mechanism.
3. Hydraulic chuck can satisfy the function of shackles and power-off protection.
4. The sliding and extending & retracting function of the mast makes it convenient for the bottom of mast to touches the ground or platform, thus the drill rig will be more stable.
5. The swinging arm and mast can do luffing movement, which satisfy the request of multi-angle drilling.
6. The range of spindle rotating speed is wide and the torque is large.
Technical data------drilling machines in tunnel
Drilling depth |
Φ55mm drilling rod |
300m |
Drill rod spec |
Φ55×1500mm |
||
Φ71×1500mm | ||||||
Φ71mm drilling rod |
200m |
|||||
The range of spindle rotating speed |
425-1280 rpm |
The max.rotating torque of spindle |
795N.m |
|||
The working pressure |
25MPa |
Spindle stroke |
1600mm |
|||
The max. lifting force of drill head |
62KN |
The max.feeding force of drill head |
33KN |
|||
The sliding stoke of mast |
495 mm |
The swing angle of mast bracket (left&right) |
90°
|
|||
The swing angle of arm(up and down) |
100° |
Power unit |
YB225M-4(dIICT4) |
|||
Explosion-proof electric motor |
45KW/1480 rpm |
|||||
Dimensions |
Main machine(L*W*H) |
2950*950*1850 mm |
weight |
Main machine |
1000kg |
|
Power unit |
1050kg |
|||||
Power unit(L*W*H) |
1900*980*1320 mm |
|||||
Operation cabinet |
140kg |
|||||
Operation cabinet(L*W*H) |
540*360*1080 mm |
|||||
Communication with the overseas customers ------drilling machines in tunnel
Package------drilling machines in tunnel
To protect drilling rigs during sea transportation, we give them proper packing.
HF130, HF80,HF150E,HF150,HF200,HF30: Wooden case
HF-3,HF-4,HFDX-6.HF-8,HFT200,HFT350B: Plastic woven bag
Spare parts: Wooden case or plastic woven bag
Quality guarantee ------drilling machines in tunnel
