Mineral mixer for sale
Introduction
Mixing barrel is made up of a motor to drive triangle generation impeller wheel rotation, stirring barrels Mixing barrel Drugs and pulp mixing fully, increases the drug reaction time improved drug quality of necessary equipment, this machine is suitable for mining, also used for mixing of various kinds of chemicals. Stirring barrels are suitable for all kinds of metal, mainly used for mixing, before the flotation is potions and pulp mixing, stirring can also be used for other non-metallic mineral. It USES the concentration is not more than 30% (by weight) of fixed composition particle size less than 1 mm. It is in the form of a flat circular spiral drum radiation impeller mechanical agitator.
Application
Mineral powder mixer is suitable to all kinds of metal ore, especially for the mixing before the ore dressing, which is just the full mixing of pharmaceutical and sufficiently slurry can also be the mixing of the other non metal material.
For the mineral powder mixer ,the using concentration cannot be greater than 30 %( by weight), and the particle size of the fixed component is less than 1mm. the form of it is the flat bottomed bucket radiation cycle with the spiral impeller mechanical agitation.
Features:
1. Compact structure, good seal, and feed port settings the block gray board, to prevent the mist playing.
2. Stir mixing blades fanned when stirred media contact area.
3. In the mineral powder mixer , the nozzle row set, more water is uniform and can adjust.
4. Leftover ash and low settings box at the bottom of the watershed to ensure that the equipment no dead ends.
5. Mine mixing tube equipment advanced performance, the quality of the finished product is stable, stir rapid discharge.
Main technical parameters:
size of the internal groove |
Effective Volume
(m3)
|
Stirrer |
Motor |
Overall Diamension |
Weight
(Kg)
|
||||
|
Diameter
(mm)
|
Height
(mm)
|
Diameter
(mm)
|
Speed
(r/min)
|
Model |
Power
KW
|
The high
(mm)
|
Maximum length
(mm)
|
||
1000 |
1000 |
0.58 |
240 |
530 |
Y100L-6 |
1.5 |
1665 |
1300 |
685 |
1500 |
1500 |
2.2 |
400 |
320 |
Y132S-6 |
3 |
2386 |
1690 |
861 |
2000 |
2000 |
5.6 |
550 |
230 |
Y132ML-6 |
4 |
3046 |
2381 |
1240 |
2500 |
2500 |
11.2 |
625 |
230 |
Y160M-6 |
7.5 |
3546 |
2881 |
3462 |
3000 |
3000 |
19.1 |
700 |
210 |
Y200L2-8 |
22 |
4325 |
3266 |
4296 |
Zhengzhou Huahong Machinery Equipment Co., Ltd. is located in Zhengzhou National Hi-Tech Industrial Development Zone, Henan Province. Our company has passed ISO9001 international quality system certification. Our company has two industrial plants of 10,000 square meters and we have 200 sets of large and medium-sized processing, welding and assembly equipment, with the maximum lifting capacity of 150 tons.
The Certificates of Zhengzhou Huahong Machinery Equipment Co.,Ltd
Welcome to visit our factory anytime !!!
Please contact us for more details:
If you have any needs on our Mineral Mixer , please feel free to contact us by sending emails to us or through skype ! We will be very happy to provide our best prooduct and professional service for you! Thank you!
