Polyester Fabrics-dehydration Fabric-WJW 2250903
- Shanghai or Ningbo
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Huading | |
| Model Number | WJW 2250903 | Usage | Liquid Filter | |
| Type | Filter Elements | Material | Polyester | |
| Hole Shape | Other, herringbone | Length | order | |
| Width | order |
Product Description
Specifications
Polyester fabric for sludge dehydration and filter press.Product Name:Polyester fabrics-dehydration fabric-wjw2250903
Diameter of warp:0.50mm
Diameter of weft:0.90mm
Density yarn/cm:warp:22
Density yarn/cm:weft:4.8-5.1
Permeability:3050
Mesh/inch:56
Usage:For dryer of paper making.For non-woven cloth forming. For sludge dehydration and filter press
type | Diameter(mm) | Density yarn(cm) | air permeability | Mesh(inch) | usage | ||
Warp | Weft | Warp | Weft | ||||
WJW12901052 | 0.90 | 1.05 | 12+0.5 | 5.5+0.5 | 2814 | 30 | Applicable for metallurgy ,mining and sludge dehydration |
WJW1290118 | 0.9 | 1.10 | 12+0.5 | 4+0.5 | 3800 | 30 | |
WJW1670903 | 0.70 | 0.90 | 16-17 | 4-4.5 | 3664 | 41 | |
WJW2050603 | 0.50 | 0.60 | 20.5+0.5 | 6.5+0.5 | 2550 | 52 | For sludge dewatering of environment protection |
WJW2050703 | 0.50 | 0.70 | 20.5+0.5 | 6.0+0.5 | 2800 | 52 | |
WJW2050803 | 0.50 | 0.80 | 20.5+0.5 | 5.5+0.5 | 3419 | 52 | |
WJW2050903 | 0.50 | 0.90 | 20.5+0.5 | 5.0+0.5 | 3842 | 52 | |
WJW2250803 | 0.50 | 0.80 | 22 | 5.5+0.5 | 3050 | 56 | |
WJW2250903 | 0.50 | 0.90 | 22 | 4.8-5.1 | 3400 | 56 | |
WJW2550908 | 0.50 | 0.90 | 25.0+0.5 | 7.0+0.5 | 2212 | 64 | Filter cakes tend to peer off;applicable for sludge dehydration of sewage treatment factories,Paper mills and chemical industry |
WJW2750705 | 0.50 | 0.70 | 27-28 | 8.2-8.5 | 1769 | 69 | |
WJW4035505 | 0.35 | 0.50 | 12.0+0.5 | 12.0+0.5 | 1200 | 105 | |
HD 005 | 0.30 | 0.30 | 32 | 18.5 | 1100 | 82 | |
