Polyester Mesh for Sludge Dewatering-WJW 2750705
- Shanghai or Ningbo
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Huading | |
| Model Number | WJW 2750705 | Usage | Liquid Filter | |
| Type | Filter Elements | Material | Polyester | |
| Hole Shape | Other, herringbone | Thickness | 1.76mm | |
| Length | order | Width | order |
Product Description
Product Name:polyester fabric for sludge dewatering2750705
Diameter of Warp 0.5mm
Diameter of Weft:0.7m
Density yarn(cm): Warp:27-28
Density Weft(cm):8.2-85
Air permeability:1769L/m²S
This product is specially designed for wastewater treatment plants as sludge dewatering mesh belt. It enjoys the features of air and water permeation, while not allowing the sludge. Due to its unique structure, the sludge will get easily off the belt after filtration. Easy cleaning and long service life.
type | Diameter(mm) | Density yarn(cm) | air permeability | Mesh(inch) | usage | ||
Warp | Weft | Warp | Weft | ||||
WJW12901052 | 0.90 | 1.05 | 12+0.5 | 5.5+0.5 | 2814 | 30 | Applicable for metallurgy ,mining and sludge dehydration |
WJW1290118 | 0.9 | 1.10 | 12+0.5 | 4+0.5 | 3800 | 30 | |
WJW1670903 | 0.70 | 0.90 | 16-17 | 4-4.5 | 3664 | 41 | |
WJW2050603 | 0.50 | 0.60 | 20.5+0.5 | 6.5+0.5 | 2550 | 52 | For sludge dewatering of environment protection |
WJW2050703 | 0.50 | 0.70 | 20.5+0.5 | 6.0+0.5 | 2800 | 52 | |
WJW2050803 | 0.50 | 0.80 | 20.5+0.5 | 5.5+0.5 | 3419 | 52 | |
WJW2050903 | 0.50 | 0.90 | 20.5+0.5 | 5.0+0.5 | 3842 | 52 | |
WJW2250803 | 0.50 | 0.80 | 22 | 5.5+0.5 | 3050 | 56 | |
WJW2250903 | 0.50 | 0.90 | 22 | 4.8-5.1 | 3400 | 56 | |
WJW2550908 | 0.50 | 0.90 | 25.0+0.5 | 7.0+0.5 | 2212 | 64 | Filter cakes tend to peer off;applicable for sludge dehydration of sewage treatment factories,Paper mills and chemical industry |
WJW2750705 | 0.50 | 0.70 | 27-28 | 8.2-8.5 | 1769 | 69 | |
WJW4035505 | 0.35 | 0.50 | 12.0+0.5 | 12.0+0.5 | 1200 | 105 | |
HD 005 | 0.30 | 0.30 | 32 | 18.5 | 1100 | 82 | |
