High Quality Safe Circuit Breaker

High Quality Safe Circuit Breaker thumbnail-1
High Quality Safe Circuit Breaker photo-1
US$ 0.4 - 1 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
GASIM
Model Number:
GSB9N&GSB9X
Contact Supplier Request Quote Chat Now
Shanghai Gasim Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name GASIM
Model Number GSB9N&GSB9X
Type Mini
Poles Number Other, 1P 2P 3P 4P

Product Description

    safe circuit breaker



Product introduction

GSB9N&GSB9X c curve circuit breaker is mainly used for protection against overload and short circuitunlder,rated voltage 230V/400V,and rated current  from 0.5A to 63A.Their high current limitation capability to realize the high selection.The products have high breaking capablity ,can reach 10KA.Also having accurate current tripping and setting.Free incoming-line direction of power supply.Small dimension and one modular quantity width .

Product parametert

Type GSB9N&GSB9X
Number of poles 1P 2P 3P 4P
Rated current(A) 0.5 1 2 3 4 6 10 16 20 25 32 40 50 63
Rated frequency 50/60HZ
Rated voltage(V) 230V/400V
Rated breaking capcity(kA) 10
Max fuse than can be connectd to 100A gl(>10KA)
Selection grade 3
Work enviromment temperature -5 to +40°c
Electrical life 8000
The length of exposed plane 45mm
Enclosure height 80mm
Enclosure width 17.5 mm evey pole(monopole)
Moutily manner The standard IEC 35mm rail
Terminal manner Dual purpose terminal can commect generatrix and wire
Terminal block capacity Conductor 1-25mm
Generatrix thickness 0.8-2mm



Product  show

high quality safe circuit breaker



high quality safe circuit breaker

high quality safe circuit breaker



high quality safe circuit breaker



Product's advantage for GSB9N&GSB9X   c curve circuit breaker

 1.Our products have the guarantee period of 24 calendar months,that is a high quality and reliability;

 2. The deliveries exactly in accordance with customer orders;

 3.  The fast transportation;

 4. Our products have an excellent ratio between price and quality ,you can possess them by competitive price   and high quality.

 5.GSB9N&GSB9X mini circuit breaker has high short-circuit breaking capacity,even can reach 10KA .






Packaging & Shipping





  standard export packing for  safe circuit breaker

  high quality safe circuit breaker


Our Services



(1)Warranty   ( 24 months warranty  )

1. The warranty starts from the delivery date from our factory;

2. During the warranty, any defective product will get repaired or replaced for free ;

3. It is beyond the warranty as the products breaked by the violence , the carelessness or repaired , altered without authorization.



 (2)Lead Time

1. Sample orders will be delivered from our factory within 7 working days.

2. General orders will be delivered from our factory within 7-15 working days.

3. Bulk orders will be delivered from our factory within 25 working days at most



(3)Shippment

1. By EMS, DHL, FedEx, TNT, UPS or other express.

 2. By our forwarding agent (by air or by sea).

3. By your own forwarding agent.

4. By domestic forwarding agents to any city in China







Company Information









  high quality safe circuit breaker

                                                                                     Our factory

   we are a manufacturer & exporter , we are sure that we can best support our customers with high quality products and perferential products.

high quality safe circuit breaker



                                                                              Taking part in Canton fair

Our markets

North America No3 Rated of buyer 12.5%
South America No4 Rated of buyer  7.5%
Europe No2 Rated of buyer  19.2%
Asia No1 Rated of buyer  35.5%
Africa No5 Rated of buyer  3.24%




FAQ







Certification :



Certified Picture  Certification Name Certified By Product Name & Model No.
high quality safe circuit breaker ISO9001:2000 EACC, ANAB Scope:  Sales of Sales of electric appliances .For example: sensors, relays, voltage stabilizers, AC contactors circuit breakers, distribution boxes, industrial plugs & sockets and others  .
 high quality safe circuit breaker

CE



EPRE

  Mini Circuit Breake&GSB6-63
 high quality safe circuit breaker  ETL  ITS  Mini Circuit Breaker&GSL7-63
high quality safe circuit breaker GS TUV PIR CEILING LAMP&GSL3002B
high quality safe circuit breaker SAA SAA Mini Circuit Breaker &N-7B
high quality safe circuit breaker CE EPRE STANDALOE SENSOR&GSA001
