Specifications
55mm Backset Garage Door Body Lock Bar Art.1K017Mortise Door Lock Body
Usage: Garage Door
Surface: Nickel Plated
Product: 55mm Backset Garage Door Body Lock Bar Art.1K017
Description:
Mortise Door Lock Body for Garage Door
55mm Backset Garage Door Body Lock Bar
1. Backset: 55mm
2. Latch Bolt: Zamak with nickel plated
3. Dead Bolt: Zamak with nickel plated
4. Forned: Steel with nickel plated
5. Lock Case: Steel with nickel plated
6. Turn: with 1 turn
7. Follower: 9 x 9mm
8. Test level: 200,000 times operation
9. Screw: Concealed 3 pc screw for striker and 2pc screw for forend
10. Matching: Suitable for interior wooden door with thickness more than 40mm
Suitable for bolt through furniture and escutcheons
Suitable for sprung and unsprung lever furniture
* Front & striking plates available in radius or rectangular
Photo and Drawing:
Available Color for Forend:
| 1. BSN | Brushed Satin Nickle | ||||||
| 2. SN | Satin Nicke | ||||||
| 3. CP | Chrome Plated | ||||||
| 4. AB | Antique Bronze | ||||||
| 5. AC | Antique Copper | ||||||
| 6. GP | Golden Plated | ||||||
| 7. White | White powder coating | ||||||
| 8. YZP | Yellow zinc plated | ||||||
| 9. 10B | Blacked | ||||||
Packing and Other Details:
| 1.Inner packing | One piece per white box or color box with customer logo | ||||||
| One piece per hanging paper card with customer logo | |||||||
| 2.Out packing | 30 pair per carton box | ||||||
| 3.Sample | Available against payment | ||||||
