Help Center4-20mA Turbo Pressure Sensor Cheap Pressure Sensor Pipe Pressure Sensor
Related Products
-
4-20mA Piezoelectric Pressure Sensor Engine Oil Pressure Sensor Low Cost Water Pressure SensorUS$ 0.1 - 200MOQ: 1 Unit -
4-20mA Fuel Rail Pressure Sensor Generator Oil Pressure Sensor Cheap Pressure SensorUS$ 0.1 - 500MOQ: 1 Unit
-
4-20mA Piezoresistive Pressure Sensor Brake Pressure Sensor Mems Pressure SensorUS$ 0.6 - 200MOQ: 1 Unit
-
4-20mA Ceramic Pressure Sensor Boost Pressure Sensor Steam Pressure SensorUS$ 0.6 - 500MOQ: 1 Unit
-
4-20mA Ceramic Pressure Sensor Mini Pressure Sensor Water Pipe Pressure SensorUS$ 0.6 - 50MOQ: 1 Unit
Based on piezoresistive silicon technology, IP10 silicon pressure transmitter uses isolated stainless steel diaphragm as sensing element. This product is fully tested by computer automatically, and trimmed by laser for zero and sensitivity in a wider temperature range. Its amplifier circuit is built in stainless steel housing, to transform sensor signal into standard output signal. This transmitter features integrated construction, rigid and robust, high measuring accuracy, good long term stability, and is suitable for pressure measurement in general industry applications.
This product is widely used for pressure measurement and control of petroleum, chemical-industry, metallurgy, power station and hydrology, etc.
l Power reverse polarity protection
l frequency interference resistance
l 0.5%Overall accuracy
l piezoresistive silicon technology
l ]high accuracy, high resolution
l digital chip compensation
Ref. Temp.:25℃ | |||||
parameter: |
Min. |
Typ. |
Max. |
Unit |
Remarks |
|
Accuracy(include linearity, hysteresis and repeatability ) |
-0.25 |
|
+0.25 |
%Span |
1 |
Long stability(1year) |
-0.25 |
|
+0.25 |
%Span |
|
Total tolerance |
-1.0 |
|
+1.0 |
%Span |
2 |
Compensation Temp. |
-20 |
|
+85 |
℃ |
|
Working Temp. |
-40 |
|
+125 |
℃ |
|
Storage Temp. |
-40 |
|
+150 |
℃ |
|
Burst Pressure |
5X |
|
|
Rated |
|
Virbration |
-20 |
|
+20 |
g |
3 |
Shock |
50 |
|
|
g |
4 |
Recycles |
10 |
|
|
million |
|
Overload Pressure |
2X |
|
|
Rated |
|
Weight |
82 |
|
|
grams |
|
Compatible Media |
|
304/316 |
|
|
|
|
Contact the factory for special model
|
|
|
|
|
|
IP10B |
IPS Pressure Transmitter With Larger Hirschmann Connector |
|||||
IP10N |
IPS Pressure Transmitter With Small Size |
|||||
IP10D |
IPS Pressure Transmitter With Digital LCD Display,RS485 Output |
|||||
IP10C |
IPS Pressure Transmitter With Cable |
|||||
IP10P |
IPS Pressure Transmitter With Packard Connector |
|||||
IP10W |
IPS Pressure Transmitter With 433M Wireless Transmission |
|||||
|
3 |
0.5~4.5V(Three-Wire) |
||||
|
4 |
1~5V( Three-Wire ) |
||||
|
5 |
4~20mA( Two-Wire ) |
||||
|
6 |
0~5V( Three-Wire ) |
||||
|
7 |
0~10V( Three-Wire ) |
||||
|
9 |
Output type according the customer request |
||||
|
|
M |
M20X1.5 |
|||
|
|
N |
1/4-18NPT |
|||
|
|
O |
M12X1.5 |
|||
|
|
P |
M10X1.0 |
|||
|
|
Q |
1/8NPT |
|||
|
|
R |
G1/4 |
|||
|
|
Z |
According the customer request |
|||
|
|
|
|
xxxK |
0~xxx KPa |
|
|
|
|
|
xxxM |
0~xxx MPa |
|
|
|
|
|
xxxB |
0~xxx Bar |
|
|
|
|
|
xxxP |
0~xxx Psi |
|
|
|
|
|
|
G |
Gauge |
|
|
|
|
|
S |
Seal |
|
|
|
|
|
A |
Absolute |
IP10B |
5 |
R |
- |
016B |
G |
|
1) Please let us know the following information about the pressure transmitter
Requirements | ||
NO |
Technical Parameters |
|
1 |
Pressure range |
|
2 |
Output signal |
|
3 |
Cable length |
|
4 |
Quantity |
|
2) We will give you a competitive price and make invoice for you
3) After you payment, we will start to produce them for you.
4) We will ship goods by DHL,UPS ,Fedex.... If you have special require, please let me know
