Specifications
water well drilling and rig1.High pulling torque gyroscope
2.Hydraulic lifting jack
3.Oil pumpsets
4.Windlass mechanism
China well-know water well drilling rig of 200 m deep
model KW20 / KW30 Water well drill rig
KW20 |
KW30 |
||
Total weight(Kg) |
7500 |
9500 |
|
size(mm) |
5100×2300×2850 |
5200×2300×3200 |
|
Travel speed(Km/h) |
0~2.5 |
0~2.5 |
|
Diesel Drive type |
YC6B125-K10 |
YC6B150Z-T21 |
|
Drive parameter |
92Kw/2200rpm |
110Kw/2100rpm |
|
Ground clearance(mm) |
280 |
280 |
|
journey(mm) |
1000 |
460 |
|
hammer |
DHD360(DHD380) |
DHD360(DHD380) |
|
Climb slope ability( °) |
25 |
25 |
|
Drill depth(m) |
200 |
300 |
|
Work wind pressure(MPa) |
1.05-2.46 |
1.05-2.46 |
|
Air consumption(m3/min) |
16-30 |
16-40 |
|
Drill rod(mm) |
φ76,φ89 |
Φ89,φ102 |
|
Drill rod length(mm) |
3000 |
3000/4000 |
|
Drill hole diameter(mm) |
φ115-254 |
φ168-300 |
|
Push journey(mm) |
2400 |
1750 |
|
propulsion(N) |
45000 |
50000 |
|
Lifting Power(N) |
95000 |
150000 |
|
Spindle Rotary Speed(rpm) |
slow |
60 |
43/52/69 |
fast |
105 |
85/102/125 |
|
Advantage
1.Safe and stable traveling system
2.Centralized operating system of Mobile Drilling Rig for Sale
3.Powerful feeding and rotating system of Mobile Drilling Rig for Sale
4.Easy operation and high efficiency as the hydraulic feeding be taken
5.As the ball type chuck and the driving rod, it can complete no-stopping rotating while the spindle relift.
The pressure indicator of bottom hole can observe and control the well conditions easily.
6.Close levers, convenient to operate.
7.Compact size and light in weight are easy to set up and transport on working plains and mountain area.
Package and Delivery
Applications:
The drilling rig is mainly used for geological general investigation and exploration, road and tall
building foundation exploration, kinds of hole in concrete structure, river levees,civil wells and earth
temperature central air-conditioner,etc
Our factory:
1. KAISHAN is the only manufacturer in china which is able to mass produce the motor powered and diesel powered portable air compressor, breaking the monopoly of foreign brand in the air compressor.
2. Good adaptability: automatically control the air delivery of diesel engine by matching the demand of air consumption, which equal to frequency conversion control in motor power screw air compressor
3. Operation parameter is straightforward, with multiple warning and shut down protection device
Exhibition
Our Factory produce all kinds of air compressor and rock drill and drill rig, any feedback from you will be highly appreciate.
