5 in 1 New Design Combo Heat Press Machine ,multifunctional Machine From Direct Factory

5 in 1 New design combo heat press machine ,multifunctional machine from direct factory

product pictures :

This combo mug heat press machine ( 5 in 1 ) can imprint 11oz, 14oz, 15oz coated mugs with higher efficiency (5 mugs at every 3 minutes), suitable for big quantity mugs printing.

Feature Fully digital temperature control Higher efficiency (5 mugs at every 3 mins) Stable in quality & competitive in price Easy to adjust the pressure Electricity saving & durable Solid steel welded framework FREE CD demonstration 1 year warranty

Parameter Dimension 84 (L)*38(W)*30 (H) CM Net weight 24kg

Max Mug height 10.5 cm Heating plate size 150 * 230 mm Heating power 1.4 KW Power 220 V/50 Hz 110 V/50 Hz Working temperature 160-200 Degree centigrade.

Features:

♦ Metal Base

♦ Anti-Rusty & Scratch-resistant

♦ Digital temperature & time setting

♦ Automatic alarm, Temperature & time recycle

♦ Transfer 5 mug at the same time

Specification:

♦ Machine Type: Manual, 5-in-1

♦ Mug Heater: Dia.6-7.5cm for 6oz,9oz,10oz etc Mug

           Dia.7.5-9.0cm for 11oz,15oz etc Mug

♦ Controller: 5 Individual Digital Temp & 5 Timer

♦ Voltage: 120V/ 220V

♦ Power: 1400W

♦ Time Range: 0-480 sec.

♦ Maximum Temp: 225 C

♦ Temperature Accuracy: ±0.5%

♦ Packing Size: 84*38*30cm

♦ Gross Weight: 24kg

Technical parameters:

Application:

Fuction Baking color logo, photo image or picture on the mug surface for advertising, gift purpose with artistic and applied effects.

advanced characters :

1.Higher efficiency

2.Easy to adjust the pressure

3.Fully digital temperature control

 sample of mug photo :

Warranty and Maintenance:

1,One-year guarantee.
2,Pressure: Adjust pressure screw clockwise to increase the pressure, counter clockwise to decrease the pressure
3,Time: Check and adjust the position of the jiggle switch in the rear machine case if the buzzer not warn or keep warning when time is out.
4,If press the pressure handle,the handle would be spring back automatically, please adjust the adjusting screw downward. After finished the printing, the handle may be too heavy to hold up, please adjust the adjusting screw upward.
5,Please check the circuit while the heat board is not available after the machine was on several minutes.
6,The natural life of the Silica Gel Board is 10000 times working.
7,The natural life of the Heat Board is 10000 times working.
8,Please feel free to contact us without any delay if there is any problem in the quality.

Notice:
1. The machine must be connected with the ground wire!
2. Do not touch the heat board while heating!
3. Do not touch the heat board once finish working as time is needed to cool down.
4. Please keep children away from the machine!
