Insulative Define Thermal Insulation For Power Semiconductors

FOB Price

USD $32 - $54 / Square Meter

100 Square Meters(Min.Order)

Supply Ability 2000 Square Meter / Square Meters per Month
Port shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	SHEEN
Model Number	SC900FG	Type	Insulation Sheet
Material	Composite Polymer	Application	High Voltage
Tensile Strength	450

Product Description

Insulative Define Thermal Insulation For Power Semiconductors

Product Information

Product Name	Insulative Define Thermal Insulation For Power Semiconductors
Item No.	SC900FG
Color	Gray, red brick
Construction & compostionn	Silicone elastomer, thermally conductive ceramic
Thickness (inch/mm)	0.2-0.5mm
Specific Gravity, (g/cc)	2.5
Hardness, (Shore A)	45
Tensile Strength, (psi)	450
Continuous Use Temp °F/ °C	-60 to 200°C
Dielectric Breakdown Voltage,(V)	>5000
Dielectric Constant, (1000 Hz)	5.5
Volume Resistivity ohm-meter	5.0 X 10¹³
Fire rating	94 V0
Thermal Conductivity,(W/m-K)	2.0
Configurations Available	Can be die-cut into specific dimensions; - Adhesive coatings are optional
Introduction	The SC900FG series products are the high-efficiency insulation ones with thermal conduction properties.The supplement of the insulation base film made by silica gel into the heat-conduction material creates a great effect on both the insulation and heat conduction.
Features and Benefits	- 2.0 W/mK thermal conductivity - Electrically isolating - High breakdown voltage - ROHS compliant -High tensile strength
Typical Applications Include	- Power supply - Automotive electronics - Motor controls - Power semiconductors - High pressure interface
