3.5m3 Motomixer Self Loading Mobile Concrete Mixer
| Brief Introduction of self loading mobile concrete mixer: |
Self-loading concrete mixing station is an on-site construction vehicle that combine features with concrete batch processing equipment, concrete transport and concrete mixing station. Self-loading concrete mixing station feature combines self-loading, weighing, mixing and discharging.This new type of machine will lead the concrete industry in next decade.
Put cement, sand and gravel into the drum and let the mobile concrete mixing station do the rest.
A small concrete station is formed by 2 mobile concrete mixer, 1 cement tank and 1 water tank.
1.Low upfront cost
2.Reduce transportation cost
3.Minimize labor cost
4.Maximize job efficiency
| Feature of self loading mobile concrete mixer: |
2. Labor-saving
3. 4 wheels driving, 4 wheels steering
4. Accurate electric weighing system
5. The mixing unit is sewing hydraulically through 270 degree for high discharge over 1.8m to the four sides of the vehicle.
6. Loading, weighing, pumping, mixing, delivering and discharging.
| Parameter of self loading mobile concrete mixer: |
Name |
Specifications |
||
Mixing system |
Drum capacity: 4.4m3 Discharging capacity: 3.5m3/tank Double helix, emergency unloading cover. Reverse when unload. Slew hydraulically through 270 degree for high discharge over 1.8m to the four sides of the vehicle. |
||
Capacity |
Capacity: 4tanks/hr 14m3/hr 110m3/day 33000m3/year |
||
Diesel engine |
Commins engine: 4BTA3.9-C110 Rotate speed: 2200r/min Rated power: 82KW |
||
Transmission |
4 wheels drive, 4wheels steering |
||
Speed |
Low: 0-9km/hr High: 0-20km/hr |
||
Hydraulic system |
Closed system Hydraulic driving pump Hydraulic mixing pump Hydraulic driving motor Hydraulic mixing motor |
||
Loader control |
Hydraulic 4 way stick |
||
Loader |
600L Hydraulic valve |
||
Chute |
Angle control Hydraulic |
||
Water supply |
Hydraulic water pump |
||
Brake |
Hydraulic brake Front and rear independent system |
||
Tire |
16/70-20 |
||
Electrical system |
24V |
||
Tank |
Water tank: 2x380L Diesel tank: 150L Hydraulic oil tank: 125L |
||
Weight |
7500KG |
||
Dimension |
LxWxH: 7.1x2.44x3.3m |
||
Weighing |
Electronic weighing system Water meter |
||
| Factory Show: |
Henan DASION Machinery Co., Ltd (Henan Dasion Mechanical Installation Co., Ltd.)
was founded in 1999, covering an area of 33500 m2, having 150 workers and 6 professional research personnel.
’DASION’ brand was created and protected at 2010, for over market and high-quality request Chinese clients only.We are one of the best manufacturers of top quality concrete construction equipment –such as concrete batching plants, concrete truck mixers, concrete pumps and related equipment and spares etc.
In China, our central marketing office is 750m2, more than 80 staffs working here; In Singapore, Pakistan, Thailand, UAE, Libya, we also have marketing office or company for business extending.
Our products are widely recognized and trusted by users and can meet continuously developing economic and social needs. We can provide Óne-stop’ service in concrete equipment field. The professional technology and perfect sales service can meet your various of requirement.
1. Payment Item : 30% of total price should be paid by T/T as down payment; 70% balance payment should be paid by T/T before delivery.
2. Delivery Time : 10-20 working days after advanced payments .
3. Packing : standard exporting package or according to customers' requirements.
4. Shipping: Ocean shipping
| Customer Reviews : |
| Our Services: |
One-stop service and solution provider in concrete equipment field.
We can supply you Independent concrete mixer, Complete concrete batching plant, Concrete truck mixer, Concrete pump, construction machine such as concrete poker vibrator, plate compactor etc.
50 service engineers are working at clients’ project, or 24 hours working on standby, ready to provide comprehensive, professional, fast and seamless service to the end users.
| Building Friendship: |
| Certification Show: |
1. What kind of concrete mixer is you need?
2. How to choose concrete batching plant?
3. How big and how many concrete mixer truck is what you need?
4. What else can DASION provide, besides of concrete equipment?
Attentions:
If you are interested in our products, please do not hesitate to contact us on TradeManager client. Or, you can click here to send us an inquiry.
Your inquiry will be given prompt attentions and reply within 12 hours.
