Sell in Pakistan Diesel Engine Concrete Pump Capacity 125cbm/hr

DSTP-48 Concrete Truck Pump

1. Max. pumping height: 47.7m

2. Pumping system: Adopt steel plates all from SWEDISH SSAB, Original GERMANY STEIBEL transfer case and REXROTH pump/valve group

3. Bucket: Big-capacity collecting bucket affords no dead angle and easy cleaning

4. Control system: Adopt original GERANY HBC wireless remote-control device and SIEMENS electric components

Main technical parameters of DSTP-48 Concrete Truck Pump

In working condition:
Transport capacity in theory--------------------------------------------------125m³/h
Pumping capacity index--------------------------------------------------------586MPa.*m³/h
Max. concrete pressure--------------------------------------------------------8.5MPa
Bucket volume-------------------------------------------------------------------620L
Bucket top surface height from the ground--------------------------------1400mm
Distribution valve form---------------------------------------------------------“S” valve
Max. pumping radius-----------------------------------------------------------43.7m
Max. pumping height-----------------------------------------------------------47.7m
Max. pumping depth------------------------------------------------------------34.3m
Delivery pipe’s diameter-------------------------------------------------------Φ125mm
Tail hose’s length----------------------------------------------------------------3m
Pumping pipe’s rotary range--------------------------------------------------365°
Boom’s section number--------------------------------------------------------5

In driving condition:
Max. speed-----------------------------------------------------------------------80km/h
Min. turning radius-------------------------------------------------------------11000mm
Brake distance------------------------------------------------------------------10m
Approach angle-----------------------------------------------------------------25°
Departure angle-----------------------------------------------------------------10°
Truck chassis brand------------------------------------------------------------SINO/ISUZU
Engine max. output power----------------------------------------------------273kw (1800r/min)
Engine max. output torque---------------------------------------------------1460N.m (1080r/min)
Fuel consumption limit---------------------------------------------------------40L/100km
Full-load weight------------------------------------------------------------------40000kg
Outline dimension---------------------------------------------------------------13300x2500x4000mm

(Parameter is changed without prior notice.)
