Radiant heat floor panel

Specifications

Radiant heat floor panel
1.Wall mount / freestanding
2.Slim design
3.Silent working
4.Safety device & energy saving

Radiant heat floor panel

Model TBK030-E15



 Features

1.French size design, Slim and compact, Unique structure, body thickness is only 64mm

2.Sheathed aluminum heating element for durability and efficient heating transfer

3.Working silently, with rapid, wide-spread and even airflow transfer

4.Water splash proof,IP24 approval, can be installed in bathroom

5.Over-heat safety protection

6.With electronics thermostat for temperature setting

7.Easy to install by wall mounted bracket or castors for free standing (optional)

8.Ionizer for heath care and nature environment (optional)

9.Humidifier lets you feel comfort, avoid dry air (optional)

10.Tip-Over safety protection (optional)

11.Towel dryer for rapid clothes drying (optional)

12.Handle for easy and safety moving (optional)















Technical Data



Power	1000W/600W/400W (TBK030-M10)	1500W/1000W/500W (TBK030-M15)	2000W/1200W/800W (TBK030-M20)
Heating Area(sqm)	14-16	18-20	22-26
Product Size(mm)	460x69x400	595x69x400	830x69x400
N.W/G.W(kg)	4.7/5.8	5.8/6.9	7.7/8.9
Packing Sizes(mm)	600x130x453	735x130x453	970x130x453
LoadingQty(20ft)	765pcs	625pcs	475pcs
LoadingQty(40ft)	1615pcs	1320pcs	999pcs
LoadingQty	1898pcs	1550pcs	1175pcs







Component





New Generation Heating Element

1)T-Extra and Duo-X heating Elements.

2)European quality X-shape sheathed heating element with newest structure big diffuser.

3)Unique multi-power design.

4)Unique composition:strong aluminum alloy and structure increase the efficiency and proof from distortion.

5)Seal heating spiral,Teflon protection and X-Ray QC bring durability for long-life using.







 Humidifier

1)Any heater working, it wil make room air become dry.

2)Timberk heater totally solve this problem by our patent design-Timberk humidifier.

3)Timberk special heater humidifier can realize water into air along with heater woking.let you enjoy fresh nature air in your room.







Ionizer

1)Bring forest to your home-Timberk lonizer.

2.)Eliminate bad smells,adverse materials(for example; formaldehyde from house decoration) and smokes in air, refuse second-hand smoking.

3)Collect dusty and floated pellets in air, make air clear, Cut off bacteria spreading.

4)Creat active oxygen, remove your body tired, inspire yourself.







Towel Dryer

1)Luxury design with stainless steel or chromed steel.

2)Convenient for installing and hiding on heater body.

3)Rapidly make your towel, clothes to be dry.









LED 24 hour timer

1.LED display

2.Adjustable temperature in Normal and Economic setting modes

3.Thermostat for temperature setting and automatic control   5°C-30°C

4.Timer 24 hours

5.User setting memory function

6.Anti-frost function

7.3 power selection:Economy,Normal,Express

8.Child safety lock



 ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------
