Home > Consumer Electronics > Washing & Drying Machine & Parts > Washing Machine Parts > 5/8 AC/DC 12v/24v/36v/110v/220v/240v ,vertical 2 Channel Plastic Solenoid Inlet Water Valve Male 1/2 3/4G

5/8 AC/DC 12v/24v/36v/110v/220v/240v ,vertical 2 Channel Plastic Solenoid Inlet Water Valve Male 1/2 3/4G

5/8 AC/DC 12v/24v/36v/110v/220v/240v ,vertical 2 Channel Plastic Solenoid Inlet Water Valve Male 1/2 3/4G thumbnail-1
5/8 AC/DC 12v/24v/36v/110v/220v/240v ,vertical 2 Channel Plastic Solenoid Inlet Water Valve Male 1/2 3/4G photo-1
US$ 2 - 10 MOQ: 200 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
XG
Model Number:
XGF-C58G0011-B
Contact Supplier Request Quote Chat Now
Jinhua Xingguang Precision Electric Appliance Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name XG
Model Number XGF-C58G0011-B
  1. Product Name: solenoid valve.
  2. Model:
  3. Working Voltage:AC/DC ,12v/24v/36v/110v/220v/240v    Power grade:4W,5W,6W,7W,8W
  4. rated operational voltage   DC:DC6V,DC9V,DC12V,DC24V,DC36V,DC110V,DC220V(Detection use voltage lower 15%)                                                                               AC:AC6V,AC9V,AC12V,AC24V,AC36V,AC110V,AC220V ETC.(Detection use voltage lower 15%)
  5. Working pressure::0.01-0.6MPa. 0.02-0.2Mpa
  6. Pressure resistance:1.5Mpa,2.0Mpa,   10minNo exceptions
  7. Application of fluid: Public water used
  8. Current capacity:200-3000mL/min
  9. Medium Temperature: 0-100°C
  10. Service life : 100,000 views.
  11. Installation dimensions: Influent Plug G1 / 2, the water plug G 1/2.
  12. Structure: Pilot-start the performance is good.
  13. Other: Customer special requirements can be designed.
  14. Small quantity available.





5/8 AC/DC 12v/24v/36v/110v/220v/240v ,vertical 2 channel Plastic solenoid inlet water valve male 1/2 3/4G5/8 AC/DC 12v/24v/36v/110v/220v/240v ,vertical 2 channel Plastic solenoid inlet water valve male 1/2 3/4G

5/8 AC/DC 12v/24v/36v/110v/220v/240v ,vertical 2 channel Plastic solenoid inlet water valve male 1/2 3/4G





parameter list      (under 20°C )



  • Valtage (V) Power (W) current (A) DC resistance(Ω)
    DC12 4.00 0.33 42±0.9
    DC12 4.50 0.39 30±0.6
    DC12 5.00 0.42 28±0.6
    DC12 6.00 0.52 22±0.5
    DC12 7.00 0.58 20±0.5
    DC24 4.50 0.19 119±2.0
    AC9 5.00 0.43 10±0.5
    AC12 4.50 0.37 15±0.5
    AC12 5.00 0.43 16±0.5
    AC24 5.00 0.20 55±1
    AC110 4.50 0.04 1.2±0.05K
    AC220 4.50 0.02 4.6±0.20K
