YSPM500V 12.1' inch colored, high definition TFT screen portable patient monitor
Features: portable patient monitor
12.1' inch colored, high definition TFT screen
Lightweight, compact and portable
Parameters: SPO2, ECG, NIBP, TEMP, RESP
Suitable for DOG, CAT and HORSE etc.
72 hours graphic and tabular trends of all parameters
32 seconds full-disclosure waveform review
500 NIBP measurement data can be stored and recalled
Storage and recall of 500 SpO2 measurement data
Built-in rechargeable Lithium battery
Technical Specifications: portable patient monitor
1. Parameters: SPO2, ECG, NIBP, TEMP, RESP, PR, RR. Optional function: ETCO2 and internal printer.
2. Power supply
AC power adapter, AC 85~265V/ 50Hz/60Hz;
lithium battery.
3. SpO2
Range: 0%-100%.
Accuracy: ±2% at 70-100%;<70%, undefined.
4. Pulse rate
Range: 30-250bpm.
Accuracy: ±2bpm at 30-250bpm.
5. NIBP
Method: Oscillometry
Modes: Manual/Auto/Comtinuous
Auto measure time: Adjustable
Measurement range: 10-270mmHg
6. ECG
Lead mode:3-lead or 5-lead
Lead selection:I;II;III,avR;avF;V
Heart rate range:Adult:15-300bpm;Pediatric/Neonatal:15-300bpm
ECG waveform:2 channals
Accuracy: ±1 bpm or ±1%,which is greater
S-T segment detection;measurement range: -2.0mv~2.0mv
Alarm:Yes,audible and visual alarm,alarm events review
7. Respiration
Method:RA-LL impedance
Range:Adult:0-120rpm;pediatric/neonatal:0-150rpm
Apnca alarm:Yes
8. Temperature
Range:0-500C
Accuracy: ± 0.10C
Channel: Dual-channel
Environment Specification: portable patient monitor
Operating Temp.: 0 to 45°c
Storage Temp.: -20 to +60°c
Relative Humidity: 30 to 95%(Operating), 10 to 95%(Storage)
Standard Package: portable patient monitor
HK-M5000V Main Uint
Veterinary SpO2 Probe
5-leads ECG Cable (mini clip)
NIBP Cuff for VET
NIBP Extension Tube
Power cable
Battery
User manual
et operating lamp
patient monitor
patient monitor
patient monitor
YSPM500V 12.1' inch colored, high definition TFT screen veterinary patient monitor
veterinary patient monitor
