Home > Products > gearless Motor > 8 inch 36V brushless gearless electric scooter motor hub motor brushless hub motor gearless hub with braking device
8 inch 36V brushless gearless electric scooter motor hub motor brushless hub motor gearless hub with braking device
Negotiable
/ Piece
10 Pieces(Min.Order)
- 0 per Month
You May Like
-
DC motor from Haiyan Long Bo factory for Hydraulic equipments
-
traction motor GE761,D77/78,GE752,D29
-
Maxon motor
-
High torque BLDC tattoo motor 2016RB low-start voltage diameter 20mm tattoo motor long lifespan tattoo motor for tattoo gun
-
High torque BLDC tattoo motor 2016RB low-start voltage diameter 20mm tattoo motor long lifespan tattoo motor for tattoo gun
-
High torque BLDC tattoo motor 2016RB low-start voltage diameter 20mm tattoo motor long lifespan tattoo motor for tattoo gun
Product Details
| Place of Origin: | Jiangsu, China | Brand Name: | LIJIU | Model Number: | ND-WZDA-03 |
| Usage: | Electric Bicycle, Other, Electric Bicycle, Electric Scooter | Certification: | CE | Construction: | Permanent Magnet |
| Commutation: | Brushless | Protect Feature: | Other | Speed(RPM): | 900~1100 |
| Continuous Current(A): | 5~6 | Output Power: | 250~350 | Voltage(V): | 24/36/48 |
| Efficiency: | Other |
Product Description
Electric Motor Kit Set with braking device and tyre.
Max speed is 40KM/H . The tyre diameteris 200mm, Dropout size is 120mm.
Easy to operate by yourself.
If you want to DIY an electric scooter with this hub motor, we also can offer you : controller, brake lever, throttle and driven wheel.
Special DIY acceptable
Product advantage:
1,Easy to operate, steady working systemand performance .
2,High quality materials make the motor keep working at high temperature.(around 40°)
3,Motor has adoptair tire , which is perfect for shock absorption.
4,with braking device realizes the more simple structure.
Specifications
Model | ND-WZDA-03 |
Rated Voltage(V) | 24/36/48 |
Rated Power(W) | 250-350 |
Speed Range(rpm) | 900-1100 |
Dropout Size(MM) | 120 |
Cable Length(MM) | 600 |
Efficiency(%) | >79 |
Noise(dB) | <54 |
Hall optional
Can be customized
