2016 New Automatic Case Maker YL-AFM450AL which is controlled pneumatically
- 500 Unit / Units per Month
- Ningbo Port China
- T/T PayPal
- Bookpackaging integrated equipment
- Cloud warehousemultifunction packaging machine
- Vegetablescombined packaging equipment Bookmultifunction packaging machine
- Sweetcombined packaging machine
- Fruitmulti-functional packaging machine Cloud warehousecombined packaging machinery
- Automatic Screw Counting Packing Machine
Product Details
Condition: | New | Function: | Boxing, Gluing | Application: | Other, Machinery & Hardware |
Packaging Type: | Cartons, Case | Packaging Material: | Paper | Automatic Grade: | Automatic |
Driven Type: | Electric | Voltage: | 5KW/380V 3phase | Power: | 60kw |
Place of Origin: | Zhejiang, China | Brand Name: | Yinlong Brand | Model Number: | AFM450AL |
Dimension(L*W*H): | 8200x2200x1600 | Certification: | CE+ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Automatic Case Kmaer
Model No. YL-AFM450AL/L
H.S. No. 84798200.90
Fully automatic machine cover
Characteristic.
1 the machine feidahong adopts back-push feeding system, the overall movement full pneumatic control , simple and reasonable structure.Adjust
the width of
2 piles of paper platform using the center of concentric adjustment, simple operation and no Error.
3, Cooper scraper new design, to effectively prevent the rolls, Paul The normal operation of the machine.
4, using imported ultrasonic double detection device, operation simple, effective To prevent double sheet of paper.The feed table with linear guide
rail and servo motor control to send
5 cardboard, accurate positioning fast Speed.
6, the cardboard feeding table is automatically shut down for lack of cardboard, product waste reduction Product rate.
7, below the conveying belt adopts high-power suction fan, so that the paper conveying more stable Accurate.
8, paper feeding and positioning system adopt imported high-precise photoelectric control device, to make the paper and cardboard location more
accurately.
9, hem with automatic repair unique angle, edge trimming mechanism, guaranteed the product The qualified rate.
10. The machine adopts PLC control, simple operation, direct display in machine fault Computer touch screen, convenient troubleshooting.
MAIN TECHNICAL PARAMETERS | ||||
Model | AFM450/450A | AFM540/540A | AFM450AL/AFM450L | AFM540AL/AFM540L |
Paper size(AxB) | MIN:130x230mm | MIN:130x230mm | MIN:130x230mm | MIN:130x230mm |
MAX:480x830mm | MAX:570x830mm | MAX:480x1030mm | MAX:570x1030mm | |
Paper thickness | 100-200g/m2 | 100-200g/m2 | 100-200g/m2 | 100-200g/m2 |
Cardboard thickness(T) | 1-3mm | 1-3mm | 1-3mm | 1-3mm
|
Finished product size(WxL) | MAX:450x800mm | MAX:540x800mm | MAX:450x1000mm | MAX:540x1000mm |
MIN:100x200mm | MIN:100x200mm | MIN:100x200mm | MIN:100x200mm | |
Spine(S) | 10mm | 10mm | 10mm | 10mm |
Folded paper size(R) | 10-18mm | 10-18mm | 10-18mm | 10-18mm |
Max quantity of cardboard | 6 pieces | 6 pieces | 6 pieces | 6 pieces |
Precision | ±0.5mm | ±0.50mm | ±0.50mm | ±0.50mm |
Production speed | ≤25 sheets/min | ≤25 sheets/min | ≤22 sheets/min | ≤22 sheets/min |
Motor power | 5kw/380v 3phase | 5kw/380v 3phase | 5kw/380v 3phase | 5kw/380v 3phase |
Heater power | 60kw | 60kw | 60kw | 60kw |
Air supply | 350L/min0.6Mpa | 350L/min 0.6Mpa | 350L/min 0.6Mpa | 350L/min 0.6Mpa |
Machine weight | 3000kg/3200kg | 3000kg/3500kg | 3600kg/3300kg | 3900kg/3500kg |
Machine dimension | L8200xW2200mm | L8200xW2300mm | L9000xW2200mm | L9000xW2300mm |
Standard Export Packing with wood pallet
To ship within 30 days after payment ain advance
Latest Technology.(International latest technology)
High Precision Processing.(12 sets of CNC machining center, more than 50 sets of processing machines.)
Standardization Production. (6S management)
High-end Electric Appliance.(Japan Omron PLC, Japan SMC Pneumatic Components, France Schneider Electrical Components, Japan Yaskawa Servo Motor, Italy GMG Motor, Germany P+F ultrasonic checker, America LEUZE Sensor etc. First class quality, European UL and CE Standard.)
First-class Performance.(Power save; larger size, faster speed, and higher precision)
Advanced after-sales service.(over 50 countries and regions such as Europe, America, Africa, the Middle East and Southeast Asia etc.)
Distinctive Customer Service.(Every parts is marked with serial number)
Ruian Yinlong Machinery Factory located in South Development Zone, Ruian City which is an enterprise specialized in the production of foodstuff machinery and packing machinery equipments.
Its production premise currently covers an area of over 5000sqm.With more than 100 techinical staff in possession, it boasts abundant technical strength and strong concept in technological innovation,in line with the tenet ever since its establishment of Quality first and customers supreme, automatic case maker, Earth cover box gluing machine, High speed automatic folding machine, Double edging machine have been highly appraised by users for their dependable quality.
YinLong will as always holding hund redfold confidence and high responsibility, offer its novelly designed elaborately made and favorably priced products as well as consummate after-sale service to our bothnew and regular customers, striving for a brilliant tomorrowside by side.
******************************************************************************************************************************
Ruian Yinlong Machinery Factory is a professional production of printing and packaging machinery enterprise. Modern industrial city is located in zhejiang ruian. Over several years, we are vigilant and demands on themselves, and the service of the extensions to reach the most fine point, to put the effort in the pursuit of customer performance increase the value of the long and self affirmation, adhere to the "quality to exploit market, beg the development with the prestige" the policy, all think the client for sale as the goal.
Our factory technical force is abundant, the production equipment, test means perfect, the management level of excellence, the collection "scientific research, development, manufacturing, sales, and service" as an organic whole. Main products: automatic husk machine, heaven and earth cover pasting box machines (shoe machine), glue machines, slot machines, flatten machine, ruffled machine, posted kok machine, the product sale network cover all over the country more than 20 provinces, municipalities, autonomous regions, and some products are sold to overseas.
Facing the changeable market, our factory insists on "high quality products, the most satisfactory service" as the objective, wholeheartedly welcome new and old customers, people from all walks of life to visit, negotiate for cooperation, create resplendent brilliant tomorrow.
Customers and suppliers are our permanent business partners. The open-minded triumph is our promise to our partners and our hopes and self-confidence to our brand. We attach importance to brand, and have
built an advanced sales system while planning development, relying on brand, and credit business.
Since its establishment, its products are not only sold t0 30 provinces and cities, but also are exported to the countries and regions like Europe, South America, the Middle East, Southeast Asia, etc.. We have a unified sales network. Our company has built a customer service centre, perfect management system of customer relations and perfected customers' records, introduced new sales idea, taken part target customers,
put forth effort to train the customersl faith for Yinlong and expanded continually our markets.
Products Quality Control
Production Capacity
General Information
SN | Common Failures | The cause of the problem | Troubleshooting |
1 |
Machine doesn't work | A. Fuse FU B. Air switch is damaged | Replacing the fuse FU Replace the air switch |
2 | Conveyor belt does not work | A.Frequency converter due to overload automatic stop B.Phase voltage is too low frequency converter due to overload automatic stop. C.Transmission motor damage |
A.Check the overload causes B.Check the voltage C.Replace the motor |
3 | Automatic glue does not work | A. Glue pump damage A glue pump motor damage C.Hose on the road congestion D.Contactor KMI damage E.Suction hose road not seal | A.Replace a glue pump B.Replace a glue pump motor C.Clean the hose on the road D.Change the contactor KMI E.Check |
4 | Blower is not working | A.Damage of contactor KM2 B.Phase voltage 380 v is not normal | A.Change the contactor KM2 B.Check the phase voltage C.Replace the blower |
5 | Glue not | A.The paper curl B.In rubber scraper and the rubber roller clearance is too small | A.Flatten the paper B.Is stainless steel panel on the scraper and rubber roller clearance |
6 | A plastic inequality | A.The paper is rough B.Stainless steel blade and rubber roller clearance is too large C.Glue is too thin D.The paper copper scraper location is not correct | A.Choose flat paper B.Adjust the stainless scraper q gap with glue C.Please adjust the thickness of the glue D.To adjust copper scraper location |
7 | The paper is not smooth | A.Copper has been smooth blade tip B.Copper scraper tip too, paper is easy to cut C.Copper blade not clean D.Copper blade position is not correct | A.Dressing copper blade B.Fixed copper blade C.Scrub copper blade D.To adjust is copper blade position |
