IVECO Hongyan 6X4 Dump Truck With Best Price
US$ 45,000 - 50,000
/ Unit
1 Unit(Min. Order)
- Any port of China
- T/T Credit Card
You May Like
Product Details
| Drive Wheel | 6x4 | Capacity (Load) | 11 - 20t | |
| Horsepower | 251 - 350hp | Condition | New | |
| Transmission Type | Manual | Emission Standard | Euro 4 | |
| Fuel Type | Diesel | |||
| Gross Vehicle Weight | 25000 | Place of Origin | Hubei, China | |
| Brand Name | IVECO | Model Number | CQ3254HTG384 | |
| Dimensions (L x W x H) (mm) | 8285,8375,8475,8785x2500x3510,3350 |
Product Description
Specifications
1. IVECO technology made in china2. IVECO FIAT CURSOR engine
3. Comfortable, Safe, Reliable ,Economic ,Competive price
IVECO Hongyan 6X4 dump truck with best price
| Type | CQ3254HTG384 | |
| Drive type | 6×4 | |
| Weight | GVW (kg) | 25000 |
| Kerb mass (kg) | 12090 | |
| Rated load(kg) | 12780 | |
| Actual pay load (kg) | 30000-50000 | |
| Dimensions | Overall Dimension(L×W×H) (mm): | 8285,8375,8475,8785×2500×3510,3350 |
| Cargo body size (L×W×H)(mm) | 5600,5800,6200×2300×1090 15m3-21m3 | |
| Front / Rear overhang (Chassis) | 1435/1675,1435/1765,1435/1865,1435/2175 | |
| Wheel base(mm) | 3775+1400 | |
| Track width(mm) | 2006/1850/1850 | |
| Performance | Max.speed (km/h) | 80 |
| Approach / Departure angle (°) | 23/20 | |
| Engine | Brand | CURSOR 9 (Originated from Fiat leading technology ,Good performance: low rev., big torque; Less fuel: less 5% than the like; Low noise: 3 db less than the like; Low cost: less 10% accessories than the like, max. 60,000 km engine oil replacement ; mature &reliability: over 1 million users in Europe. ) |
| Model | F2CE0681C*B052 (C9 340) | |
| Power(kw/HP) | 250kw/340HP | |
| Max.Torque (N.m )/rpm | 1300Nm | |
| Displacement (L) | 8.7 | |
| Fuel Injection | Electronically Controlled High Pressure Common Rail System | |
| Emmission Standards | Euro 4 | |
| Fuel Consumption | 196g/KW.h | |
| Option | C9 290/C9 310/C9 380 | |
| Transmission | Brand | FAST ( Low fault rate, easy gear changing, low fuel ) |
| Model | 12JSD160T | |
| Control type | Manual | |
| Gear Shift | 12 forward and 2 reverse speeds | |
| Option | 10JSD140 (10 forward and 1 reverse speeds) | |
| Clutch | Type | Single Plate,Diaphragm-spring |
| Diameter (mm) | φ430 | |
| Action | Mechanical type,Hydraulic and pneumatic operation | |
| Steering | Type | Rotary Valve Steering |
| Model | ZF8098 German hydraulic steering with power assistance | |
| Chassis | Type | 865×317×(8+8) |
| Axles | Brand | HONGYAN |
| Front axle | 9000kg | |
| Rear axle | 13000kg(each) Double reduction driving cast steel axle withinter-wheel differential and differential lock. | |
| Ratio | 4.8/5.73/6.72 | |
| Tyres | Type (Standard) | 12.00R20 |
| Option | 12.00-20/11.00-20/11.00R20/12R22.5 | |
| Fueltank | Tank capacity (L) | 350 |
| Material | Aluminum magnesium alloy | |
| Cab | Type | GENLYON (Long cab with low roof, made by 0.8-1.5mm thick sheet, overall stamping & precise welding, 80% double face galv. sheet. High safety, Firm structure, Strong anti-bumping, Lasting anti-erosion, High used car price) |
| Equipments | Can-Bus ,A/C,Electric windows,One rear window,Mechanical clerestory, Mechanica suspension cab,Mechanical suspension seat with seatbelts,One sleeping bed,Hydraulic reversal cab,with USB,can play radio with MP3 format | |
| Option | Electricity reversal cab,Electricity heated rear-view mirror,Air suspension driver seat with handle and seatbelts,4 Point air suspension | |
If need more information ,please feel free to contact me.
Welcome to visit our company in China!
