Dongfeng 6x4 Dump Truck Normal Loading 39Ton

SPECIFICATION

Model

DFL3258A3

Drive

Left Hand Drive or Right Hand Drive

Configuration

6×4

Normal loading

capacity

39Ton

Off road loading

capacity

60Ton

Wheelbase

1^st axle-2^nd axle

2^nd axle-3^rd axle

3800mm

1450mm

Complete Dimensions

(L×W×H)

8450×2500×3450 Only for reference, should be subject to the existence.

Cargo box(L×W×H)

5800, 6000,6200 ×2500mm×1500,1600,1800mm

side board 8mm back board:10mm or as your option

Engine

L290-33

213KW 6 Cylinder, Turbo Diesel, 290HPs/2100RPM, Displacement 8900ml, Euro 3 emission standard, water cooling diesel engine.

Gear box

FAST-9 Gear-box ,9 forward+ 1 reverse

Suspension

Leaf spring + Shock Absorber 10/12

Clutch

Φ430mm, pushing-type Diaphragm spring.

Brakes

Service brake: Two-circuit air pressure braking.

Parking brake: Air pressure braking

Exhaust brake: Air pressure braking

Steering

Power steering, with adjustable steering wheel.

Frame section(mm)

300×90×(8+8)

Tyres

11.00R20/12.00R20

Electrical system

Alternator 28V/80A,Batteries 12V/175Ah

Fuel tank capacity

350L, Steel tank.

Kerb weight

16500kgs

Payload capacity

20000kg-45000kg

Axles loading capacity

Front

Rear

7,000kgs

16,000kgs ×2 (wheel side reduction)

Cab

D310 Single sleeper, tilt cab hydraulic and mechanical overturn cab, left-hand drive.

Accessories

Tool box, Air conditioner, cold boot, interaxial differential, wheel redactor.

Performance

Max. speed 85km/h
