Flexo Printing Cylinder Plate Mounting Machine
- NINGBO CHINA
- Money Gram Credit Card
You May Like
-
8 Colors Paper Material Wide Web Flexo Printing Machine For Fax Paper,Paper Cup,Paper Bag
-
Roll to Roll Wide Web Flexo Printing Machine ( 150m/min Can Print Paper Bag,plastic Film Ect,super Printing Quality From Ruian )
-
USD116,700 150m/min Unit Type Flexo Printing Machine 6 Colors ( Printing Precision 0.1mm,for Paper Cup,paper Bag)
-
HAS VIDEO 150m/min Unit Type High Speed Flexo Printing Machine ( High Printing Precision 0.1mm,for Paper Cup,paper Bag) Quality Choice
-
Wide Web High Speed Flexo Printing Press With Anilox Roller ( 150meter per Minute ) for Carton ,paper Bag,box ,with Slitting
-
HAS VIDEO 0.1mm Wide Web High Speed Flexo Printing Press For Paper Cup and Paper Bag,4 ,5 ,6 Colors Kraft Paper Printing Machine
Product Details
| Condition | New | Plate Type | Other, plater mounting machine | |
| Place of Origin | Zhejiang, China | Brand Name | XH | |
| Model Number | TB | Usage | Other, rubber plate | |
| Automatic Grade | Automatic | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Flexo plate mounting machinery is used with flexo printing machine,it can stick the plate on the printing cylinder AccuracyFlexo printing cylinder plate mounting machine
1. Description:
a) This machine adopt high precision linear guide raids for horizontal positioning, the up and
down position of camera is adjustable, use pricision screw rod system
b) With magnify zoom lens, high definition CCD camera, and LCD displayer
c) Can individually move the two camera, conveniently and accurate positioning the cross line.
d) The CCD camera can be adjusted in six direction, the parallelism is adjustable, high precision
of plate mounting and registing.
e) The plate focus with micro-adjustment system, so that can accurate moving the plate and
correct contrapose the datum line;after mounting, can check the precision directly and
assure the plate mounting quality.
f) Pnuematic locking system, convenient loosen and tighten, fast plate mounting, easy operation,
greatly improved the working efficiency.
g) Suitable for flexo plate and resin plate printing.
2. Main parts:
* Linear guide raids: HIWI brand or ABBA brand from TaiWan
* CCD camera: MINTRON brand of TaiWan
* Zoon lens: China Optical instrument factory
* LCD displayer: SUMSUNG brand or PHILIPS brand
3. Main Technical Specification:
Model | TBJ-450 | TBJ-650 |
Plate mounting width | 120~450mm | 120~650mm |
Plate cylinder diameter | 55~260mm | 55~260mm |
Power | 0.5kw | 0.5kw |
Overall dimension | 128x600x1050mm | 128x700x1050mm |
Weight | 90kg | 100kg |
Voltage | 95V~245V/1P | 95V~245V/1P |
Air supply | 3~4mpa | 3~4mpa |
more details,please contact us.
