Product Details
| Products Status | Stock | Cabinet Standard | ANSI/EIARS-310- D | |
| Material | High-quality cold-rolled steel, seamless steel board | Size | vary | |
| Place of Origin | Tianjin, China | Brand Name | Shiyu | |
| Model Number | NCB |
whole package or flat package with export carton
Product Description
Specifications
1.Exquisite design with precise dimension2.Good ventilation and heat dispersing
3.Frame is made of high quality materials
server cabinet 19 inch (6-46U) network cabinet
Products Description :
NCB cabinet includes numerous features that will save time and increase the installation options for the user . Supplied fully assembles as standard with transit castors and adjustable feet . If you're uncertain, utilize our expertise and recommendations until you're confident you have exactly that you need! We will build, paint and configure your server cabinet to your exact specification and ship it directly to you .
Features and benefits
- Meet the requirement of ANSI/EIARS-310- D, criterions to manufacture
- Material: seamless steel board.
- Good ventilation and heat dispersing .
- User can add the cable fixtures accordingly .
- Powder coated to protect against rust, oxidization, scratches, lacquer peeling, strong acid and alkali erosion .
- Flexible vertical rail ‘s thickness must up to 2mm.
- Framework using high strength steel with a 800kg.weight capacity.
- Rack's side panel can be easily assembled and disassembled from the outside without using any tools .
- Screw-less appearance for a smooth and clean look.
- It has been widely applied in the field of computer data network, page, wiring, Pa broadcasting, soundtrack system, subway train
Part number configuration tool:
- NCB18---66 ( 18U)
NCB 18-66 ( x) Use the x to specify the capability of the cabinets:
- 18= 18 U 22 = 22 U 27 = 27 U 32 = 32U 42=42U 46= 46U
Part number | Description(mm) | Width(mm) | Depth(mm) | High(mm) | Carton measurement(mm) | Carton weight |
NCB18-66-*#& | 18U NCB Cabinet | 600 | 600 | 1000 | L 610×W 630×H 1040 | 45KG |
NCB22-66-*#& | 22U NCB Cabinet | 1200 | L 610×W 630×H 1240 | 55KG | ||
NCB27-66-*#& | 27U NCB Cabinet | 1400 | L 610×W 630×H 1440 | 65.5KG | ||
NCB32-66-*#& | 32U NCB Cabinet | 1600 | L 610×W 630×H 1660 | 76KG | ||
NCB37-66-*#& | 37U NCB Cabinet | 1800 | L 620×W 640×H 1880 | 87KG | ||
NCB37-68-*#& | 800 | 1800 | L 620×W 640×H 1880 | 102KG | ||
NCB37-696-*#& | 960 | 1800 | L 620×W 1000×H 1880 | 117KG | ||
NCB37-86-*#& | 800 | 600 | 1800 | L 820×W 640×H 1880 | 102KG | |
NCB37-88-*#& | 800 | 1800 | L 820×W 840×H 1880 | 127KG | ||
NCB37-896-*#& | 960 | 1800 | L 820×W 1000×H 1840 | 147KG | ||
NCB42-66-*#& | 42U NCB Cabinet | 600 | 600 | 2000 | L 620×W 640×H 2080 | 97KG |
NCB42-68-*#& | 800 | 2000 | L 620×W 840×H 2080 | 115KG | ||
NCB42-696-*#& | 960 | 2000 | L 620×W 1000×H 2080 | 128KG | ||
NCB42-86-*#& | 800 | 600 | 2000 | L 820×W 640×H 2080 | 115KG | |
NCB42-88-*#& | 800 | 2000 | L 820×W 840×H 2080 | 135KG | ||
NCB42-896-*#& | 960 | 2000 | L 820×W 1000×H 2080 | 155KG | ||
NCB47-66-*#& | 47U NCB Cabinet | 600 | 600 | 2200 | L 620×W 640×H 2230 | 107KG |
NCB47-68-*#& | 800 | 2200 | L 620×W 840×H 2230 | 127KG | ||
NCB47-696-*#& | 960 | 2200 | L 620×W 1000×H 2230 | 125KG | ||
NCB47-86-*#& | 800 | 600 | 2200 | L 820×W 640×H 2230 | 124KG | |
NCB47-88-*#& | 800 | 2200 | L 820×W 840×H 2230 | 144KG | ||
NCB47-896-*#& | 960 | 2200 | L 820×W 1000×H 2230 | 164KG |
* = front door
# = rear door
A = steel casement door
B = smoky-gray glass door with frame punched
&= color A=Balck(RAL9004) B=Gray(front door : RAL7039,cabinet : RAL7044)
