Home > Products > Height controller > Capacitor Height Controller For CNC Flame / Gantry Cutting Machine
Capacitor Height Controller For CNC Flame / Gantry Cutting Machine
- 5000 Piece / Pieces per Month
- Shanghai
- T/T Credit Card
- Co2 Welding Torches nozzle welding torch
- SC-010 Dual-Tip Flame Tube Self-ignition Mapp Gas Welding hand Torch With valve and 1.5M hose HVAC
- single flame lighter mapp gas welding hand torch hvac torches gas welding cutting torch
- welding hand torch dual torch lighter dual flame torch
- Gas torch welding
- Antorchas tig manual de soldadura Antorcha manual de gas MAPP welding hand torch triple flame lighter triple torch lighter
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | Longteng | Model Number: | LT-TG-01 |
Type: | Cutting Torch | Welding Type: | Other, flame cutting torch control | Welding Capacity: | Strong |
Product Description
Specifications
Capacitance height controller1.Full-enclosed design
2.dust-proof
3.vibration-proof
4.moisture-proof
1. Flame cutting torch height controller
2. Apply to Flame CNC cutting machine
3. Power supply: AC24V
2)Structural Features :
1. Designed for portable CNC cutting machine
2. High induction sensitivity, run smooth and stable
3. Set upper and lower limit switch inside, reduce the loss of motor, prolong the service life.
3) Applications:
Used for cutting torch auto height control of flame cutting machine, it is suitable for vast majority of imported or domestic models of flame.
4)Working Principles:
Using basic constant current of flame power source characteristics, by testing the change of flame arc voltage to test the change of Fame cutting torch height in the process, realize the control of cutting torch height.
5) Specifications:
Model Number | LT-TG-01 |
Brand Name | Longteng,OEM |
Place of Origin | Wuxi, China (Mainland) |
Certification | CE,ISO |
Loading Port | FOB Shanghai |
Driving Mode | Electric |
Mains Supply | AC24V±10%,50/60 Hz, 100 W |
Lifter Motor | DC24V motor,1-4A |
Control Box(Temperature) | -10-60°C |
HF Cable | -55°C~200°C |
Sensor Distance | 5mm-20mm,adjustable |
Accuracy | ±0.1mm |
Length of HF Cable | 1000mm |
Sensor Type | Ring |
Sensor Dimensions | Outer diameter 80 mm,Inner diameter 40 mm |
Housing Dimensions | 180 mm x 100 mm x 65 mm(L×W×D) |
Weight | Controller box 0.9 kg |
| Controller box with sensor components1.3 kg |
