Home > Products > fiber optic cable indoor > 4core in Unit Tube Fiber Optic Cable With Messenger Wire for Self-support Aerial Use
4core in Unit Tube Fiber Optic Cable With Messenger Wire for Self-support Aerial Use
- Shenzhen
- T/T Credit Card
You May Like
-
12 Core Figure 8 Fiber Optic Cable With 1.4mm Messenger Wire
-
Top Quality FTTH Fiber Cable With Steel or FRP Strength Member
-
GJXCH Ftth Fiber Cable From Shenzhen Manufacaturer
-
Good Quality GJXH FTTH Fiber Cable With Steel Strength Member
-
SM 9/125 SC to SC Duplex 3m Fiber Patch Cord
-
SM 9/125 LC-SC Duplex Fiber Optic Cable With Pvc Jacket
Product Details
| Place of Origin | Guangdong, China | Brand Name | ADP&OEM | |
| Model Number | ADP0001112 | Number of Conductors | 4 | |
Product Description
4core in unit tube Fiber Optic Cable with messenger wire for self-support aerial use
Recommended Laying methods
Self-support aerial
Applicable fields
Long distance communication and LAN
Structure Characters
Water proof layer between steel tape and cable core 8 .Figure cross section
Steel messenger wire
Double coated PE corrugated steel tape under PE sheath
Properties
Excellent water proof layer
Steel tape armored ,Excellent Anti-crush properties
Good anti-bullet properties
Messenger wire as the support member made excellent
Anti-pull performance and easy installation
Fiber range: 2-288 core
Technical data:
Cable Count | Out sheath | Weight | Minimum allowable Tensile Strength | minimum allowable Crush Load | Minimum Bending Radius | Storage | |||
(MM) | (KG) | short term | long term | short term | long term | short term | long term | (°C) | |
2 | 3.8×5.5 | 52.00 | 1000 | 200 | 1000 | 200 | 20D | 10D | -40+60 |
4 | 3.8×5.5 | 52.00 | 1000 | 200 | 1000 | 200 | 20D | 10D | -40+60 |
| 6 | 3.8×5.5 | 52.00 | 1000 | 200 | 1000 | 200 | 20D | 10D | -40+60 |
| 8 | 3.8×5.5 | 52.00 | 1000 | 200 | 1000 | 200 | 20D | 10D | -40+60 |
| 12 | 3.8×5.5 | 52.00 | 1000 | 200 | 1000 | 200 | 20D | 10D | -40+60 |
Optical Characteristics | ||||
Fiber Sort | Multimode | G.651 | A1a:50/125 | Graded-index fiber |
A1b:62.5/125 | ||||
Singlemode | G.652(A,B,C) | B1.1:Conventional fiber | ||
G.652D | B2: Zero dispersion shifted | |||
G.655 | B1.2 :Cut-off wavelength shifted | |||
G.657(A1,A2 ,B3) | B4: Main technical data for positive | |||
