Anping Green PVC Coated Hexagonal Gabion Mesh
Gabions are wire fabric containers, filled with stone at the site of use, to form flexible, permeable, monolithic structures for earth retention.
Material: High quality low carbon steel wire, galvanized wire, stainless steel wire, PVC coated wire
Weaving: Link and weaving is simple, artistic and practical
Standard: ASTM-975-97 and BS EN 10223-2:1998
Wire diameter: 1.6mm--4mm (mainly according to your requirement)
Aperture size (mm): 60x80 80x90 80x100 80x120 100x120 100x150 120x150 120x180 180x200
Yearly Output: more than six million square meters
Gabion Boxes | |||
|
Opening (mm) |
Wire Diameter(Steel Wire) |
Wire Diameter(PVC Coated) |
Strands |
60X80 |
2.00-2.80 |
2.0/3.0-2.5/3.5 |
3 |
80X100 |
2.00-3.20 |
2.0/3.0-2.8/3.8 |
3 |
80X120 |
2.00-3.20 |
2.0/3.0-2.8/3.8 |
3 |
100X120 |
2.00-3.40 |
2.0/3.0-2.8/3.8 |
3 |
100X150 |
2.00-3.40 |
2.0/3.0-2.8/3.8 |
3 |
120X150 |
2.00-4.00 |
2.0/3.0-3.0/4.0 |
3 |
Properties of Mesh | ||||||
Mesh Type |
B (mm) |
Tolerance (mm) |
Wire Diameter (mm) |
|||
Mesh |
Selvedge |
|||||
Galv. |
Galv./PVC |
Galv. |
Galv/ PVC |
|||
60 |
60 |
-4+10 |
2.2 |
2.2/3.2 |
2.7 |
2.7/3.7 |
80 |
80 |
-4+10 |
2.7 |
2.7/3.7 |
3.4 |
3.4/4.4 |
|
MESH TOLERANCE The tolerance on the opening of mesh "b" being the distance between the axis of two consecutive |
|||||
Features
• Economic.
• Just fill the stone into the gabion and seal it.
• Simple installation.
• No special technology needed.Weather proof under natural destroy, corrosion resistant.
• No collapse even under big scope of deforming.
• Sludge in the stones is good for plant growing.
• Mixed to form a integrity with the natural environment.Good permeation can prevent the damage by hydrostatic.
• Less transport freight. It can be folded together for transport and further installation.
Gabion Basket Applications
• Control and guide of water or flood
• Flood bank or guiding bank
• Preventing of rock breaking
• Bridge Protection
• Water and soil protection
• Coast protection
• Seaport engineering
• Strengthening structure of soil
• Protection of road
